HOCHIKI - ESP Addressable - ATEX, EN54 - Dual channel
📋 SPECIFICATIONS:
• Operating voltage (Un): 26.5 V DC
• Breakdown voltage (Uo): 28 V DC
• Terminal resistance (Ro): 300 Ω (Minimum)
• Short-circuit current (Io): 93 mA
• Configuration: Dual channel (Positive/Return)
• Mounting: DIN rail (35mm) with integrated earthing
• Operating temperature: -20°C to +60°C
• Dimensions (housing): 12.5 mm (width) x 115 mm (height) x 110 mm (depth)
• Approximate weight: 150 g
• Mounting type: Standard 35 mm DIN rail (EN 50022)
• Housing material: High thermal resistance reinforced polycarbonate
📦 INCLUDED:
• 1 x Z787 Zener barrier: Dual-channel intrinsically safe module.• 1 x Safety and installation data sheet• Certification label• Earthing clip
| Operating voltage (Un) | 26.5 V DC |
|---|---|
| Breakdown voltage (Uo) | 28 V DC |
| Terminal resistance (Ro) | 300 Ω (Minimum) |
| Short-circuit current (Io) | 93 mA |
| Configuration | Dual channel (Positive/Return) |
| Mounting | DIN rail (35mm) with integrated grounding |
| Operating temperature | -20°C to +60°C |
| Dimensions (housing) | 12.5 mm (width) x 115 mm (height) x 110 mm (depth) |
| Approximate weight | 150 g |
| Mounting type | Standard 35 mm DIN rail (EN 50022) |
| Housing material | High thermal resistance reinforced polycarbonate |
