X-Security 5-in-1 Video Recorder - 16 CH HDTVI/HDCVI/AHD/CVBS + 8 IP - IVS Wizsense | 1 HDD

X-Security 5-in-1 video recorder - 16 CH HDTVI/HDCVI/AHD/CVBS + 8 IP - Maximum resolution 5 MP - Audio over coaxial | SMD | AcuPick - 2 CH Face recognition - IVS Wizsense | 1 HDD

📋 SPECIFICATIONS:
• Brand: X-Security
• Video format: HDTVI / HDCVI / AHD / CVBS / IP
• Video inputs: 16 BNC channels (HDTVI / HDCVI / AHD / CVBS)
• Hybrid configuration: Up to 24 IP channels (6 MP), replacing all BNC channels
• Video/audio compression: H.265+/H.265/H.264+/H.264
• Video input resolution: CVI: 5 MP @ 25 fps; 5 MP @ 20 fps; 5 MP@10/12.5 fps; 4 MP @ 25/30 fps; 1080p @ 25/30 fps; 720p @ 50/60 fps; 720p @ 25/30 fps.; TVI: 5 MP (2560 × 1944) @ 20 fps; 5 MP (2960 × 1665) @ 20/25 fps; 4 MP @ 25/30 fps; 1080p @ 25/30 fps; 720p @ 25/30 fps.; AHD: 5 MP @ 20 fps; 4 MP @ 25/30 fps; 1080p @ 25/30 fps; 720p @ 25/30 fps.
• Video output: 1 HDMI 4K, 1 VGA
• Display resolution: HDMI: 4K (3840x2160), 1920×1080, 1280×1024, 1280×720; VGA: 1920×1080, 1280×1024, 1280×720; Resolution changes to 1920x1080, 1280x1024, 1280x720 when face recognition, IVS, SMD or AcuPick are active
• Total bandwidth: 128 Mbps
• Encoding: Encoding enhancement disabled:; Main stream:; Channels 1-4 5M-N@(1 fps–25 fps), others 5M-N@(1 fps–12 fps);; Channels 1-4 4M-N/1080p@(1 fps–30 fps), others 4M-N/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps);; Sub-stream: D1/CIF@(1 fps–15 fps);; Encoding enhancement enabled:; Main stream:; Channels 1-8 5M-N@(1 fps–20 fps), others 5M-N@(1 fps-12 fps); (4 channels can be transformed to 5MP@6 fps); Channels 1-8 4M-N/1080p@(1 fps–25 fps), others 4M-N/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps);; Sub-stream: D1/CIF@(1 fps–15 fps);; *When encoding enhancement is enabled, video quality analysis, scene change, face recognition, face detection, IVS perimeter protection and AcuPick cannot be used.
• Video bitrate: 32 kbps–6144 kbps
• Multifunction: Pentaplex: Live, recording, playback, backup and remote access
• Audio inputs: 16 BNC (audio over coaxial); 1 RCA channel
• Audio outputs: 1 RCA channel
• Two-way audio: Reusing audio input/output
• Audio compression: G.711a; G.711u; PCM
• Audio bitrate: 64 kbps
• SMD (Smart Motion Detection): Advanced motion detection based on pixel variation produced by people and vehicles, which reduces false alarms; For NVR: Up to 16 CH; For IP camera with SMD: All channels (up to 32 targets/second)
• IVS Perimeter protection: Intelligent algorithm based on person and vehicle detection with high precision, which filters out any irrelevant objects such as rain, leaves, bright lights, etc.; IVS is based on line crossing, area intrusion, and area entry, ...; For NVR: Up to 4 CH (up to 10 IVS rules)
• AcuPick: Quick search for people and vehicles up to 2 channels, on live video or recordings based on IVS Perimeter protection events
• Face detection: 6 face features.; Up to 2 channels (up to 12 face images per second for each channel)
• Face recognition: Storage of up to 10 databases with 10,000 images.; Up to 2 analog channels for live face comparison
• AI-based video quality analysis: 16 channels: Supports detection of brightness levels, dominant colors, blur, overexposure, contrast levels, and black and white.
• Scene change: 1 channel
• Irregular black block masking: 1 channel
• Recording mode: Manual, scheduled, motion detection, alarm
• Backup: USB/Network
• Internal memory: 1 SATA 3.5" HDD up to 16 TB (not included)
• Communication: RS485 (PTZ); 1 x USB 2.0 (front), 1 x USB 3.0 (back); RJ45 10/100/1000 (Ethernet)
• Remote access: Browser (ActiveX), Smartphone App or PSS software
• Operating temperature: –10 °C ~+55 °C
• Power supply: DC 12V / 2 A / <12 W (without HDD)
• Dimensions: 47.6 (H) x 260 (W) x 237.8 (D) mm
• Weight: 1 kg

📦 INCLUDED:
• 5-in-1 X-Security recorder• Mouse• 12VDC power supply
