X-Security Industrial L2 Managed Switch - 8-port 10/100 PoE (Port 1 BT up to 90W)

X-Security Industrial L2 Managed Switch - 8-port 10/100 PoE (Port 1 BT up to 90W) - Dual uplink: 1x Gigabit RJ45 and 1x Gigabit Combo - Centralized management via local web interface - DIP Switch: Extend mode (250m) and PoE Watchdog - IP30 shielded chassis suitable for DIN rail

📋 SPECIFICATIONS:
• Product category: Industrial managed Layer 2 (L2) switch
• Copper PoE interfaces: 8 × 10/100 Mbps RJ-45 (Ports 1 to 8)
• Uplink interfaces: 1 × 10/100/1000 Mbps RJ-45 + 1 × Gigabit Combo port (1000 Mbps RJ-45 / SFP)
• Network standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
• Switching capacity: 5.6 Gbps internal switching capacity
• Data transmission rate: 4.17 Mpps (Packet Forwarding Rate)
• MAC address table: 8000 independent logical entries
• Internal data buffer: 4 Mbit packet buffer memory
• Jumbo Frame size: Supports large frames up to 9216 bytes
• Network segmentation: Support for port-based VLANs up to 32 networks
• PoE standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, advanced Hi-PoE support
• PoE distribution: Port 1 ≤ 90W (Hi-PoE/bt) / Ports 2-8 ≤ 30W
• Power supply capacity: Maximum total PoE power of 90W
• PoE pin assignment: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
• PoE management functions: Power consumption control, On/Off, overload cutoff, and Green PoE
• HW DIP settings: Managed Mode / Extend Mode (up to 250m at 10Mbps) / PoE Watchdog
• Layer 2 security: Port isolation and loop detection (self-loop)
• Traffic control: Storm control (Multicast/Broadcast) and unknown Unicast suppression
• Device management: Management via web interface, logs, LLDP, and DHCP client
• Structure and materials: Fully shielded iron housing
• Protection ratings: Industrial IP30 protection grade and IK06 impact resistance grade
• Electrostatic protection: Air discharge: 8 kV / Contact discharge: 6 kV
• Lightning protection: Common mode: 4 kV / Differential mode: 2 kV
• Installation options: Dual support for DIN rail mounting or desktop
• Hardware reliability: Ultra-high MTBF of 1,014,663.76 hours of continuous operation
• Power input: Dual external power supply (Terminal block and DC Jack): 48–57 VDC, 2–1.69 A
• Net power consumption: Idling: 3.1 W / Full load (with PoE): 95 W
• International certifications: Strict compliance with CE regulations
• Operating temperature: Operating range from –30 °C to +65 °C
• Storage temperature: Storage range from -40 °C to +85 °C
• Operating humidity: 10% to 90% RH (non-condensing)
• Chassis dimensions: 154.3 mm × 110.4 mm × 30 mm (Length × Width × Height)
• Net device weight: 0.56 kg (1.23 lb) / Gross weight with packaging: 1.3 kg (2.87 lb)

📦 INCLUDED:
• 1x XS-SWI1008HIPOE-MFC-90-DIN Industrial Managed L2 Switch
• 1x External power supply
• 1x AC power cord
• 1x Terminal block for redundant input
• 1x User manual and quick start guide
• 1x Legal and regulatory documentation
