VCA Technology - model VCA-IPAi259-FR, IPAi range - 4K IR AI Fisheye IP Camera - 4K resolution, 1.5mm lens. 25m IR. - VCA video analytics (optional deep learning) - ONVIF profile S/T/M compatible, NDAA, IK10, IP67
📋 SPECIFICATIONS:
• Brand: VCA Technology
• Range: IPAi
• Model: VCA-IPAi259-FR
• Optical sensor: Sony IMX412 1/2.3” 12.3M CMOS
• Maximum resolution: 4000(H) x 3000(V)
• Minimum illumination: Color: 0.3 Lux; B/W: 0 Lux (IR LED On)
• WDR: True WDR
• Lens: 1.5mm
• Viewing angle: 360°
• Aperture: F1.8
• Shutter: Auto / Manual: 1/30 ~ 1/32000, Anti-Flicker, Slow Shutter (1/2,1/3,1/5,1/6,1/7.5,1/10)
• IR LED: High Power IR LED x 3; 25m distance
• Video compression: H.264, H.265, MJPEG
• Privacy Mask: Up to 16 zones
• Built-in video analytics: intrusion detection, detection zones and lines, tampering detection, presence, absence, loitering, entry, exit
• Optional video analytics (deep learning): people tracking, object tracking (people, cars, motorcycles), object metadata
• Ethernet: 10/100BASE-T
• ONVIF: ONVIF profile S/T/M
• Security: HTTPS (SSL), IP filtering, 802.1x, Digest Authentication
• Protocols: TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB 2), UPNP, RTCP, SSH, ONVIF
• Storage: microSD/microSDHC/microSDXC card slot (not included)
• Audio compression: G.711 u-law 8KHz, AAC LC 48Kbps at 8KHz
• Audio input: Microphone included, supply voltage: 2.4VDC (3mA), input impedance: 3K Ohm
• Audio output: Line output, maximum output level: 1Vrms
• Construction material: Aluminum (die-cast), black and white
• Housing: Fisheye
• Power consumption: DC12V max. 10.2W; PoE max. 11.5W
• Power supply: DC12V, PoE (IEEE 802.3af)
• Operating conditions: Humidity 10% ~ 90% RH (non-condensing); -30°C ~ 50°C
• Standards: FCC, CE, IP67, IK10
• Certifications: Compliant with NDAA standards
• Dimensions: Ø125mm x 58mm
• Weight: 0.5 kg
• Warranty: 2 years
📦 INCLUDED:
• VCA-IPAi259-FR camera• Installation manual and quick start guide• Mounting accessories
| Range | IPAi |
|---|---|
| Model | VCA-IPAi259-FR |
| Optical Sensor | Sony IMX412 1/2.3” 12.3M CMOS |
| Maximum Resolution | 4000(H) x 3000(V) |
| Minimum Illumination | Color: 0.3 Lux B/W: 0 Lux (IR LED On) |
| WDR | True WDR |
| Lens | 1.5mm |
| Viewing Angle | 360° |
| Aperture | F1.8 |
| Shutter | Auto / Manual: 1/30 ~ 1/32000, Anti-Flicker, Slow Shutter (1/2,1/3,1/5,1/6,1/7.5,1/10) |
| IR LED | High Power IR LED x 3 25m distance |
| Video Compression | H.264, H.265, MJPEG |
| Privacy Mask | Up to 16 zones |
| Built-in Video Analytics | intrusion detection, detection zones and lines, tampering detection, presence, absence, loitering, entry, exit |
| Optional Video Analytics (deep learning) | person tracking, object tracking (people, cars, motorcycles), object metadata |
| Ethernet | 10/100BASE-T |
| ONVIF | ONVIF profile S/T/M |
| Security | HTTPS (SSL), IP filtering, 802.1x, Digest Authentication |
| Protocols | TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB 2), UPNP, RTCP, SSH, ONVIF |
| Storage | microSD/microSDHC/microSDXC card slot (not included) |
| Audio Compression | G.711 u-law 8KHz, AAC LC 48Kbps at 8KHz |
| Audio Input | Microphone included, supply voltage: 2.4VDC (3mA), input impedance: 3K Ohm |
| Audio Output | Line output, maximum output level: 1Vrms |
| Construction material | Aluminum (die-cast), black and white |
| Housing | Fisheye |
| Consumption | DC12V max. 10.2W PoE max. 11.5W |
| Power Supply | DC12V, PoE (IEEE 802.3af) |
| Operating conditions | Humidity 10% ~ 90% RH (non-condensing) -30°C ~ 50°C |
| Standards | FCC, CE, IP67, IK10 |
| Certifications | NDAA compliant |
| Dimensions | Ø125mm x 58mm |
| Weight | 0.5 kg |
| Warranty | 2 years |
