UV-XVR301-16Q4
UV-XVR301-16Q4

Note: actual colors may vary slightly from the images due to different monitor settings and lighting conditions during shooting.

UNIVIEW

Uniview 5-in-1 Video Recorder - Easy Series - 16 CH HDTVI / HDCVI / AHD / CVBS + 8 extra IP - Audio | Alarm

SKU: UV-XVR301-16Q4
(0)
In stock
Usually shipped within 24 hours
€340,34 Final price
-8% €369,00 €340,34 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Uniview 5-in-1 Video Recorder - Easy Series - 16 CH HDTVI / HDCVI / AHD / CVBS + 8 extra IP - Audio | Alarm - Supports 1 hard disk

📋 SPECIFICATIONS:
• Brand: Uniview
• Series: Easy
• Video format: HDTVI / HDCVI / AHD / CVBS / IP
• Video inputs: 16CH BNC
• Hybrid configuration: 8 IP channels (up to 24 channels IP-only) replacing all BNC channels
• Video output: 1 HDMI, 4K (3840 × 2160) 1 VGA (1920x1080p)
• Audio inputs: 1 RCA channel
• Audio outputs: 1 RCA channel
• Two-way audio: Reusing audio input/output
• Alarm: 4 Inputs / 1 Output
• Maximum IP recording resolution: 4K
• Supported analog cameras: TVI / AHD: 8MP@12FPS (ch1-ch16); 5MP@20FPS; 4MP@30FPS; 3MP@30FPS (ch1-ch16); 1080P@30FPS; 720P@60FPS; CVI: 8MP@15FPS(ch1-ch16); 4MP@30FPS; 1080P@30FPS; 720P@60FPS; *For proper live display, the combination of resolution and FPS of the connected analog cameras must be equal to or lower than the indicated specifications, but under no circumstances higher.
• Main Stream recording encoding: 8MPLite@8FPS (ch1-ch16); 5MPLite@12fps; 4MPLite@15FPS; 3MP@15FPS(ch1-ch16); 2MP@15FPS; 720P@30FPS
• Extra Stream recording encoding: D1@30FPS
• Recording method: Manual, scheduled, motion detection
• Internal storage: 1 HDD SATA 3.5" up to 16TB (not included)
• External interface: 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
• Remote access: Web browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
• Power supply: DC 12 V / 3 A
• Dimensions / Weight: 260 mm × 251 mm × 45.8 mm / 900 g

📦 INCLUDED:
• Uniview 5-in-1 video recorder • Mouse • Adapter
Range Easy
Video format HDTVI / HDCVI / AHD / CVBS / IP
Video inputs 16CH BNC
Hybrid configuration 8 IP channels (up to 24 IP channels only) replacing all BNC channels
Video output 1 HDMI, 4K (3840 × 2160) 1 VGA (1920x1080p)
Audio inputs 1 RCA channel
Audio outputs 1 RCA channel
Two-way audio Reusing audio input/output
Alarm 4 Inputs / 1 Output
Maximum IP recording resolution 4K
Supported analog cameras TVI / AHD: 8MP@12FPS (ch1-ch16); 5MP@20FPS; 4MP@30FPS; 3MP@30FPS (ch1-ch16); 1080P@30FPS; 720P@60FPS CVI: 8MP@15FPS (ch1-ch16); 4MP@30FPS; 1080P@30FPS; 720P@60FPS *For proper live viewing, the combination of resolution and FPS of the connected analog cameras must be equal to or lower than the stated specifications, and under no circumstances higher.
Main Stream recording encoding 8MPLite@8FPS (ch1-ch16); 5MPLite@12fps; 4MPLite@15FPS; 3MP@15FPS (ch1-ch16); 2MP@15FPS; 720P@30FPS
Extra Stream recording encoding D1@30FPS
Recording method Manual, scheduled, motion detection
Internal storage 1 SATA 3.5" HDD up to 16TB (not included)
External interface 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
Remote access Web browser, CMS software (EZStation), Smartphone (EZView/EZLive)
Power supply DC 12 V / 3 A
Dimensions / Weight 260 mm × 251 mm × 45.8 mm / 900 g
