UV-XVR301-04Q4
UV-XVR301-04Q4

Note: actual colors may vary slightly from the images due to different monitor settings and lighting conditions during shooting.

UNIVIEW

Uniview 5-in-1 Video Recorder - Easy Series - 4 CH HDTVI / HDCVI / AHD / CVBS + 2 extra IP

SKU: UV-XVR301-04Q4
(0)
In stock
Usually shipped within 24 hours
€97,54 Final price
-42% €169,00 €97,54 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Uniview 5-in-1 Video Recorder - Easy Series - 4 CH HDTVI / HDCVI / AHD / CVBS + 2 extra IP - Audio / Alarms / 4K HDMI - Supports 1 hard drive

📋 SPECIFICATIONS:
• Brand: Uniview
• Series: Easy
• Video format: HDTVI / HDCVI / AHD / CVBS / IP
• Video inputs: 4 CH BNC
• Hybrid configuration: 2 IP channels (up to 6 channels IP only) replacing all BNC channels
• Video output: 1 4K HDMI, 1 VGA (1920x1080p)
• Audio inputs: 1 RCA Channel
• Audio outputs: 1 RCA Channel
• Bidirectional audio: Reusing the audio input/output
• Alarms: 4 inputs / 1 output
• Maximum IP recording resolution: 4K
• Supported analog cameras: Supports AHD input: 8MP@15fps; 5MP@20fps; 4MP@30fps; 1080P@30fps; 720P@30fps; Supports TVI input: 8MP@15fps; 5MP@20fps; 4MP@30fps; 1080P@30fps; 720P@30fps; Supports CVI input: 8MP@15fps; 5MP@25fps; 4MP@30fps; 1080P@30fps; 720P@30fps; Supports CVBS input
• Main Stream recording encoding: 8MP Lite/5MP/5MP Lite/4MP Lite/1080P/720P/CIF
• Incoming bandwidth: 40 Mbps (up to 48 Mbps after converting all analog channels)
• Outgoing bandwidth: 48 Mbps
• XVR analysis with analog cameras: Ultra Motion Detection (UMD), Face Detection, SIP
• Analysis functions performed by the XVR: Face Detection (1CH) | SIP (2 CH) | UMD (4CH)
• IP camera analysis capability: Face Detection | SIP | Blur Detection | Scene Change Detection | Auto Tracking | Object Left Behind | Object Removed | People Counting
• Recording method: Manual, scheduled, motion detection
• Network interface: 1 RJ45 10M/100M self-adaptive Ethernet interface
• Internal storage: 1 3.5" SATA HDD up to 16 TB (not included)
• External interface: 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
• Remote access: Web browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
• Power supply: DC 12 V / 10 W
• Dimensions / Weight: 47 (H) x 260 (W) x 226 (D) mm / 1.1 kg

📦 INCLUDED:
• Uniview 5-in-1 Video Recorder • Mouse • Power adapter
Range Easy
Video format HDTVI / HDCVI / AHD / CVBS / IP
Video inputs 4 CH BNC
Hybrid configuration 2 IP channels (up to 6 channels IP only) replacing all BNC channels
Video output 1 HDMI 4K, 1 VGA (1920x1080p)
Audio inputs 1 RCA channel
Audio outputs 1 RCA channel
Two-way audio Reusing audio input/output
Alarms 4 inputs / 1 output
Maximum IP recording resolution 4K
Supported analog cameras Supports AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Supports TVI input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Supports CVI input: 8MP@15fps 5MP@25fps 4MP@30fps 1080P@30fps 720P@30fps Supports CVBS input
Main Stream recording encoding 8MP Lite/5MP/5MP Lite/4MP Lite/1080P/720P/CIF
Incoming bandwidth 40 Mbps (up to 48 Mbps after converting all analog channels)
Outgoing bandwidth 48 Mbps
XVR analysis with analog cameras Ultra Motion Detection (UMD), Face Detection, SIP
Analysis functions performed by XVR Face Detection (1 CH) | SIP (2 CH) | UMD (4 CH)
IP camera analysis capability Face Detection | SIP | Blur Detection | Scene Change Detection | Auto Tracking | Object Left | Object Removed | People Counting
Recording method Manual, scheduled, motion detection
Network interface 1 RJ45 10M/100M self-adaptive Ethernet interface
Internal memory 1 SATA 3.5" HDD up to 16 TB (not included)
External interface 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
Remote access Web browser, CMS software (EZStation), Smartphone (EZView/EZLive)
Power supply DC 12 V / 10 W
Dimensions / Weight 47 (H) x 260 (W) x 226 (D) mm / 1.1 kg
