Tachyon Networks TNA-AK-S-45 Scanning Kit. - 30 dBi antenna gain for extended range. - 45° x 5° beam-steering range to ensure precision. - Supports a maximum EIRP of up to 50 dBm. - Modular design for TNA-303X base unit. - Dimensions of 180 x 150 x 150 mm.
📋 SPECIFICATIONS:
• Device type: Modular antenna kit (passive)
• Compatibility: Exclusive to TNA-303X base unit
• Antenna gain: 30 dBi
• Beam-steering range: 45° x 5°
• Maximum system EIRP: 50 dBm
• Operating frequency: 57-71 GHz (Full band: Channels 1-6)
• Supported throughput: Up to 2.3 Gbps (2+ Gbps)
• Maximum distance (System): Up to 6 km
• Polarization: Linear (supported by base radio station)
• Duplexing: TDD (supported by base radio station)
• Mounting type: Requires TNA-M-P mount (not included)
• Material: Industrial-grade for outdoor use
• Operating temperature: -30 °C to 55 °C (Supported by base radio station)
• Dimensions: 180 x 150 x 150 mm
📦 INCLUDED:
• 1x Tachyon TNA-AK-S-45 modular antenna kit.• 1x Installation and alignment documentation
| Device type | Modular antenna kit (passive) |
|---|---|
| Compatibility | Exclusive to TNA-303X base unit |
| Antenna gain | 30 dBi |
| Beam-steering range | 45° x 5° |
| Maximum system EIRP | 50 dBm |
| Operating frequency | 57-71 GHz (Full band: Channels 1-6) |
| Supported throughput | Up to 2.3 Gbps (2+ Gbps) |
| Maximum distance (System) | Up to 6 km |
| Polarization | Linear (supported by base station) |
| Duplexing | TDD (supported by base station) |
| Mounting type | Requires TNA-M-P mount (not included) |
| Material | Industrial-grade for outdoor use |
| Operating temperature | -30 °C to 55 °C (supported by base station) |
| Dimensions | 180 x 150 x 150 mm |
