Sleep mode shutdown - IP67 protection - Backup battery - Bluetooth technology
📋 SPECIFICATIONS:
• Name: Teltonika TM2500
• Technology: GSM/GPRS/GNSS/BLUETOOTH® LE
• GNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
• Receiver: 33 channels
• Tracking sensitivity: -165 dBM
• Positioning accuracy: < 2.5 CEP
• Velocity accuracy: < 0.1 m/s (with an error margin of +/- 15 %)
• Hot start: < 1 s
• Warm start: < 25 s
• Cold start: < 35 s
• Technology: GSM
• 2G bands: Quad band 850 / 900 / 1800 / 1900 MHz
• Data transfer: GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
• Data support: SMS (Text/data)
• Input voltage range: 10 - 30 V DC with overvoltage protection
• Backup battery: 1200 mAh Li-ion battery
• Specification: 4.0 + LE
• Compatible peripherals: EYE beacons and sensors, headsets, OBDII adapter, Inateck barcode scanner, universal Bluetooth® LE beacon and sensor compatibility.
• Operating temperature (without battery): -40 °C to +85 °C
• Storage temperature (without battery): -40 °C to +85 °C
• Relative humidity: 5% to 95% non-condensing
• Protection: IP67
• Battery charging temperature: 0 °C to +45 °C
• Battery discharge temperature: -20 °C to +60 °C
• Battery storage temperature: -20 °C to +35 °C for 1 month; -20 °C to +30 °C for 6 months
• Sensors: Accelerometer
• Scenarios: Green driving, overspeeding detection, jamming detection, GNSS fuel counter, DOUT control via call, excessive idling detection, unplug detection, towing detection, crash detection, auto geofence, manual geofence, trip
• Sleep modes: GPS Sleep, Online Deep Sleep, Deep Sleep and Ultra Deep Sleep
• Configuration and firmware update: FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth® wireless technology), FMBT mobile application (configuration)
• SMS: Configuration, Events, DOUT control, Debug
• GPRS commands: Configuration, DOUT control, Debug
• Time synchronization: GPS, NITZ, NTP
• Fuel monitoring: OBDII dongle
• Ignition detection: Digital input 1, accelerometer, external power voltage, engine RPM (OBDII dongle)
• Sleep mode disabled: Allows turning off the module to reduce power consumption to less than 1 mA in sleep mode
• Regulations: CE/RED, E-Mark, EAC, RoHS, REACH
| Name | Teltonika TM2500 |
|---|---|
| Technology | GSM/GPRS/GNSS/BLUETOOTH® LE |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Receiver | 33 channels |
| Tracking sensitivity | -165 dBM |
| Position accuracy | < 2.5 CEP |
| Velocity accuracy | < 0.1 m/s (with a +/- 15% error margin) |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| Technology | GSM |
| 2G bands | Quad band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B |
| Data support | SMS (text/data) |
| Input voltage range | 10 - 30 V DC with overvoltage protection |
| Backup battery | 1200 mAh Li-Ion battery |
| Specification | 4.0 + LE |
| Compatible peripherals | EYE beacons and sensors, headsets, OBDII adapter, Inateck barcode scanner, universal Bluetooth® LE sensor and beacon support. |
| Operating temperature (without battery) | -40 °C to +85 °C |
| Storage temperature (without battery) | -40 °C to +85 °C |
| Relative humidity | 5% to 95% non-condensing |
| Protection | IP67 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature | -20 °C to +35 °C for 1 month, -20 °C to +30 °C for 6 months |
| Sensors | Accelerometer |
| Scenarios | Green driving, overspeeding detection, jam detection, GNSS fuel counter, DOUT control via call, excessive idling detection, unplug detection, tow detection, crash detection, auto geofence, manual geofence, trip |
| Sleep modes | GPS sleep, online deep sleep, deep sleep, ultra deep sleep |
| Configuration and firmware update | FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth® wireless technology), FMBT mobile application (configuration) |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time synchronization | GPS, NITZ, NTP |
| Fuel monitoring | OBDII dongle |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII key) |
| Sleep mode disabled | Allows switching off the module to reduce power consumption to less than 1 mA in sleep mode |
| Regulations | CE/RED, E-Mark, EAC, RoHS, REACH |
