Teltonika UPS Equipped with two 4-pin DC ports
Teltonika UPS Equipped with two 4-pin DC ports
Regular price
€178,00
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Teltonika UPS - Equipped with two 4-pin DC ports - Adjustable input and output voltage from 9-30 VDC - Includes 2x 18650 Li-Ion battery cells - Backup time up to 6 hours for network devices - Supports DIN rail or flat surface mounting
📋 SPECIFICATIONS:
• Brand: Teltonika
• Reference model: TK-BAT120
• Component type: Industrial Uninterruptible Power Supply (UPS)
• Input voltage: 9 ~ 30 VDC
• Output voltage: 9 ~ 30 VDC (in battery mode: 12 VDC regulated)
• Internal battery type: Li-Ion (2x rechargeable 18650 cells)
• Battery capacity: 2600 mAh / 17 Wh
• Backup time: Up to 6 hours of continuous operation
• Mounting options: DIN rail or flat surface installation
• Electrical safety: Reverse polarity, overvoltage, and overcurrent (3A) protection
• LED visual interface: 1x IN PWR LED, 1x OUT PWR LED, 4x power status LEDs
• Operating temperature: 0 °C ~ 45 °C
• Physical dimensions: 30 × 100 × 85 (mm) (Height × Width × Depth)
• Net weight: 315 g
• Certifications: CE/RED, UKCA, EAC, RoHS
• Compatible models: RUT2xx, RUT95x, RUT3xx, RUTxxx, TRB14x, TRB2xx, TSW110, TCR100
📦 INCLUDED:
• 1x Teltonika TK-BAT120 UPS system
• 1x Wall power supply
• 1x Specific 4-pin power cable
• 1x User and configuration manual
| Reference model | TK-BAT120 |
|---|---|
| Component type | Industrial Uninterruptible Power Supply (UPS) |
| Input voltage | 9 ~ 30 VDC |
| Output voltage | 9 ~ 30 VDC (in battery mode: 12 VDC regulated) |
| Internal battery type | Li-Ion (2x 18650 rechargeable cells) |
| Battery capacity | 2600 mAh / 17 Wh |
| Backup runtime | Up to 6 hours of continuous operation |
| Mounting options | DIN rail or flat surface installation |
| Electrical safety | Reverse polarity, overvoltage, and overcurrent protection (3A) |
| LED visual interface | 1x IN PWR LED, 1x OUT PWR LED, 4x power status LEDs |
| Operating temperature | 0 °C ~ 45 °C |
| Physical dimensions | 30 × 100 × 85 (mm) (Height × Width × Depth) |
| Net weight | 315 g |
| Certifications | CE/RED, UKCA, EAC, RoHS |
| Compatible models | RUT2xx, RUT95x, RUT3xx, RUTxxx, TRB14x, TRB2xx, TSW110, TCR100 |
Same-day shipping if you order before 12:00 PM! In most cases, we rely on couriers with 24-hour service so your order arrives on time.
For orders under €200, the shipping fee is €15.90. For deliveries to remote areas or islands, couriers apply a surcharge to cover transport costs.
The legal warranty lasts 2 years for private individuals (consumers) and 1 year for VAT holders (professionals or companies)
