TBB Ethernet Connector Compatible with RioSun II inverters
TBB Ethernet Connector Compatible with RioSun II inverters
Regular price
€126,82
Final price
Regular price
-7%
€136,00
Sale price
€126,82
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
TBB Ethernet Connector - Compatible with RioSun II inverters - For monitoring and control via App and portal
📋 SPECIFICATIONS:
• Bandwidth: 10/100 Mbps
• Communication port: RJ45
• Standards: IEEE 802.3-2008, IEEE 1588-2008
• Bus frequency: Up to 144MHz
• Operating temperature range: -30ºC - +75 ºC (12V voltage, 60% humidity)
• Storage temperature range: -40ºC - +85 ºC
• Operating altitude: 5000m
• Relative humidity: 10 - 85%
• Protection rating: IP20
• Dimensions: 108.6 x 84.92 x 40.3 (mm)
• Weight: 200g
• Standards: CE
• Power supply: 12Vdc 500mA
• Operating voltage range: 9 - 16 Vdc
• Operating current range: 5 - 250 mA
📦 INCLUDED:
• TBB Ethernet Connector
| Bandwidth | 10/100 Mbps |
|---|---|
| Communication port | RJ45 |
| Standard | IEEE 802.3-2008, IEEE 1588-2008 |
| Bus frequency | Up to 144MHz |
| Operating temperature range | -30ºC - +75 ºC (12V voltage, 60% humidity) |
| Storage temperature range | -40ºC - +85 ºC |
| Operating altitude | 5000m |
| Relative humidity | 10 - 85% |
| Protection rating | IP20 |
| Dimensions | 108.6 x 84.92 x 40.3 (mm) |
| Weight | 200g |
| Standard | CE |
| Power supply | 12VDC 500mA |
| Operating voltage range | 9 - 16 VDC |
| Operating current range | 5 - 250 mA |
