Takex infrared beam detector
Takex infrared beam detector
Regular price
€1.162,12
Final price
Regular price
-9%
€1.272,00
Sale price
€1.162,12
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Infrared barrier detector - Compatible with radio transmitter - Wired | 4 beams | AND and OR function - Max. detection distance 100 m (adjustable) - Double Tamper | Alarm output - Battery powered
📋 SPECIFICATIONS:
• Use: Infrared barrier detector
• Detection range: 100 m outdoor
• Number of beams: 4
• Detection method: Interruption of 4 beams simultaneously or only 2 (upper or lower)
• Interruption time: 50ms, 100ms, 250ms, 500ms (selectable via DIP Switch)
• Frequency channels: 4 different channels via DIP Switch
• Outputs: NO/NC alarm output, NC tamper output, NC low battery output
• Compatibility: Compatible with radio transmitters
• Adjustment angle: Horizontal 180°(±90°), Vertical 20°(±10°)
• Operating temperature: -25ºC ~ +60ºC
• Power supply: LS33600 batteries recommended
• Power output for transmitter: 3.0 V DC
• Dimensions: 447 (H) x 114 (W) x 166 (D) mm
• Transmitter dimensions: 200 (H) x 67 (W) x 33 (D) mm
• Installation: Outdoor or indoor
📦 INCLUDED:
• Infrared barrier• Installation material• User instructions
| Usage | Infrared barrier detector |
|---|---|
| Detection range | 100 m outdoor |
| Number of beams | 4 |
| Detection method | Interruption of 4 beams simultaneously or only 2 (top or bottom) |
| Interruption time | 50ms, 100ms, 250ms, 500ms (selectable via DIP switch) |
| Frequency channels | 4 different channels via DIP switch |
| Outputs | NO/NC alarm output, NC tamper output, NC low battery output |
| Compatibility | Compatible with wireless transmitters |
| Adjustment angle | Horizontal 180°(±90°), Vertical 20°(±10°) |
| Operating temperature | -25ºC ~ +60ºC |
| Power supply | LS33600 batteries recommended |
| Power output for transmitter | 3.0 V DC |
| Dimensions | 447 (H) x 114 (W) x 166 (D) mm |
| Transmitter dimensions | 200 (H) x 67 (W) x 33 (D) mm |
| Installation | Outdoor or indoor |
