Streamax 1080P IP Dome Dashboard Camera - RJ45 PON (DC 9-15V)
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Streamax - 1080P IP Dome Dashboard Camera - 1/2.8" Progressive Scan CMOS 1080P - 2.8 mm Lens / Microphone - IP65 Protection Rating - RJ45 PON (DC 9-15V)
📋 SPECIFICATIONS:
• Brand: Streamax
• Optical sensor: 1/2.8" Progressive Scan CMOS sensor
• Resolution: 1080p (1920x1080)
• Main Stream: 1080p @30FPS
• Sub-Stream: VGA/D1/CIF @ 30FPS
• Lens: 2.8 mm (H: 104º, V: 55º)
• Minimum illumination: 0.05Lux (Color), 0 Lux with IR, F1.2
• Infrared illumination: 5 - 8 m
• Shutter: 1/30s-1/10000s
• Audio: Built-in microphone, up to 4 meters
• Audio encoding: ADPCM / G.711A / G.711U / G726
• Network interface: RJ45 10/100M
• Communication protocol: N9M
• Network protocol: TCP/IP, HTTP, DHCP, NTP, FTP
• Power supply: PON (DC 9-15V) < 2w (day) < 3.5w (night)
• Installation: Ceiling or wall mount
• Operating temp.: -40º C ~ +70º C, 90%
• Dimensions: 52.6 (D) × 96 (W) × 101.5 (H) mm
• Protection rating: IP65
📦 INCLUDED:
• ST-C25 Camera PON RJ45 Version • Installation material • Quick installation guide
| Optical sensor | 1/2.8" Progressive Scan CMOS sensor |
|---|---|
| Resolution | 1080p (1920x1080) |
| Main Stream | 1080p @30FPS |
| Sub-Stream | VGA/D1/CIF @ 30FPS |
| Lens | 2.8 mm (H: 104º, V: 55º) |
| Minimum illumination | 0.05Lux (Color), 0 Lux with IR, F1.2 |
| Infrared illumination | 5 - 8 m |
| Shutter | 1/30s-1/10000s |
| Audio | Built-in microphone, up to 4 meters |
| Audio encoding | ADPCM / G.711A / G.711U / G726 |
| Network interface | RJ45 10/100M |
| Communication protocol | N9M |
| Network protocol | TCP/IP, HTTP, DHCP, NTP, FTP |
| Power supply | PON (DC 9-15V) < 2W (day) < 3.5W (night) |
| Installation | Ceiling or wall mount |
| Operating temp. | -40º C ~ +70º C, 90% |
| Dimensions | 52.6 (D) × 96 (W) × 101.5 (H) mm |
| Protection degree | IP65 |
