Ajax integrated transmitter PIR detector Sopras - Curtain type, dual PIR on each side
Ajax integrated transmitter PIR detector Sopras - Curtain type, dual PIR on each side
Regular price
€126,82
Final price
Regular price
-5%
€134,00
Sale price
€126,82
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
PIR detector - Integrated Ajax transmitter - Curtain type, dual PIR on each side - Detection 9 m per side - Distance in open space 1600 m - Outdoor use
📋 SPECIFICATIONS:
• Technology: Dual curtain PIR
• PIR lens: 4 zones (2 per side)
• Detection range: 9 m / Installation 1~1.2m
• Frequency: 868 MHz Jeweller with included Ajax transmitter
• Transmission distance: ≤ 1600 m in open field
• Masking: Not available
• PIR sensitivity: Adjustable. 3 levels per side
• Anti-tamper: Available
• LED indication: Alarm
• DIP switch configuration: Activation, PIR and range AND/OR (independent on each side), battery saving mode and LED
• Wired outputs: Left side alarm, right side alarm, tamper power supply and transmitter
• Power supply: 1 ER14505 3.6 V battery
• Consumption: Minimum consumption (standby): 29uA / Maximum: 0.9 mA)
• Operating temp.: -20 ºC ~ 70 ºC
• Protection rating: IP65
• Dimensions: 220 (H) x 70 (W) x 60 (D) mm
• Weight: 550 g
📦 INCLUDED:
• Outdoor PIR detector• Instruction manual• Mounting material
| Technology | Dual curtain-type PIR |
|---|---|
| PIR lens | 4 zones (2 on each side) |
| Detection range | 9 m / Installation 1~1.2 m |
| Frequency | 868 MHz Jeweller with included Ajax transmitter |
| Transmission distance | ≤ 1600 m in open space |
| Masking | Not available |
| PIR sensitivity | Adjustable. 3 levels on each side |
| Anti-tamper | Available |
| LED indication | Alarm |
| DIP switch configuration | Activation, PIR and AND/OR range (independent on each side), battery saving mode and LED |
| Wired outputs | Left side alarm, right side alarm, tamper and transmitter power supply |
| Power supply | 1 x ER14505 3.6 V battery |
| Consumption | Minimum consumption (standby): 29µA / Maximum: 0.9 mA |
| Operating temp. | -20 ºC ~ 70 ºC |
| Protection rating | IP65 |
| Dimensions | 220 (H) x 70 (W) x 60 (D) mm |
| Weight | 550 g |
