Sopras integrated Ajax transmitter PIR detector - Microwave and dual curtain PIR
Sopras integrated Ajax transmitter PIR detector - Microwave and dual curtain PIR
Regular price
€189,08
Final price
Regular price
-5%
€200,00
Sale price
€189,08
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
PIR detector - Integrated Ajax transmitter - Microwave and dual curtain PIR - Dual PIR detection 9 m per side - 1600 m open space distance - Outdoor use
📋 SPECIFICATIONS:
• Technology: Microwave and dual curtain PIR
• Microwave: 24 GHz / Adjustable
• PIR lens: 4 zones (2 per side)
• Detection range: 9 m / Installation 1~1.2m
• Frequency: 868 MHz Jeweller with Ajax transmitter included
• Transmission distance: ≤ 1600 m in open field
• Masking: Not available
• PIR sensitivity: Adjustable. 3 levels per side
• Anti-opening tamper: Available
• LED indication: Alarm
• DIP switch configuration: Activation, PIR and range AND/OR (independent on each side), battery saving mode and LED
• Wired outputs: Left side alarm, right side alarm, tamper power supply and transmitter
• Power supply: 1 ER14505 3.6 V battery
• Consumption: Minimum consumption (standby): 60 uA / Maximum: 20 mA)
• Operating temp.: -20 ºC ~ 70 ºC
• Protection rating: IP65
• Dimensions: 220 (H) x 70 (W) x 60 (D) mm
• Weight: 550 g
📦 INCLUDED:
• Outdoor PIR detector• Instruction manual• Mounting material
| Technology | Microwave and dual PIR curtain |
|---|---|
| Microwave | 24 GHz / Adjustable |
| PIR lens | 4 zones (2 on each side) |
| Detection range | 9 m / Installation 1~1.2m |
| Frequency | 868 MHz Jeweller with Ajax transmitter included |
| Transmission distance | ≤ 1600 m in open space |
| Masking | Not available |
| PIR sensitivity | Adjustable. 3 levels on each side |
| Anti-tamper | Available |
| LED indication | Alarm |
| DIP switch configuration | Activation, PIR and AND/OR range (independent on each side), battery saving mode and LED |
| Wired outputs | Left side alarm, right side alarm, tamper power supply and transmitter |
| Power supply | 1 ER14505 3.6 V battery |
| Consumption | Minimum consumption (standby): 60 uA / Maximum: 20 mA |
| Operating temp. | -20 ºC ~ 70 ºC |
| Protection rating | IP65 |
| Dimensions | 220 (H) x 70 (W) x 60 (D) mm |
| Weight | 550 g |
