Integrated Ajax Transmitter PIR Detector Sopras - Microwave and dual PIR curtain - BR
Integrated Ajax Transmitter PIR Detector Sopras - Microwave and dual PIR curtain - BR
Regular price
€131,44
Final price
Regular price
-9%
€144,00
Sale price
€131,44
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
PIR detector - Integrated Ajax transmitter - Microwave and dual PIR curtain - Detection range 3 m - Anti-masking technology - 1200 m open space range
📋 SPECIFICATIONS:
• Technology: Microwave and dual curtain PIR with Anti-masking
• Microwave: 24 GHz / Adjustable
• PIR lens: 2 zones
• Detection range: 3 m / 35º
• Frequency: 868 MHz Jeweller with included Ajax transmitter
• Transmission distance: ≤ 1200 m in open space
• Masking: Available
• Anti-tamper: Available
• LED indication: Alarm
• DIP switch configuration: Anti-masking, AND/OR function, pulse counter (1 or 2), Microwave and LED
• Wired outputs: Alarm, tamper and transmitter power supply
• Power supply: 1 x ER14505 3.6 V battery
• Consumption: Minimum consumption (standby): 30 uA / Maximum: 20 mA
• Operating temp.: -20 ºC ~ 50 ºC
• Protection degree: IP54
• Dimensions: 295 (H) x 37 (W) x 32 (D) mm
• Weight: 150 g
📦 INCLUDED:
• PIR detector• Instruction manual• Mounting material
| Technology | Microwave and dual curtain-type PIR with antimasking |
|---|---|
| Microwave | 24 GHz / Adjustable |
| PIR lens | 2 zones |
| Detection range | 3 m / 35º |
| Frequency | 868 MHz Jeweller with Ajax transmitter included |
| Transmission distance | ≤ 1200 m in open space |
| Masking | Available |
| Anti-tamper | Available |
| LED indication | Alarm |
| DIP switch configuration | Antimasking, AND/OR function, pulse counter (1 or 2), Microwave and LEDs |
| Wired outputs | Alarm power supply, tamper and transmitter |
| Power supply | 1 x ER14505 3.6 V battery |
| Consumption | Minimum consumption (standby): 30 uA / Maximum: 20 mA |
| Operating temp. | -20 ºC ~ 50 ºC |
| Protection degree | IP54 |
| Dimensions | 295 (H) x 37 (W) x 32 (D) mm |
| Weight | 150 g |
