Sunell Gamma Pro - NVR3964E8 variant
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Sunell SN-NVR3964E8-J - Pro Series - 64CH IP NVR Video Recorder - Maximum resolution 12Mpx@1ch | Alarms | Audio - Bandwidth 400Mbps/400Mbps - Supports 8 hard drives (not included)
📋 SPECIFICATIONS:
• Brand: Sunell
• Series: Pro
• IP camera inputs: 64 channels
• Incoming bandwidth: 400Mbps
• Outgoing bandwidth: 400Mbps
• HDMI 1 output: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768
• HDMI 2 output: 1920 × 1080, 1280 × 1024, 1024 × 768
• VGA output: 1920 × 1080, 1280 × 1024, 1024 × 768
• Video decoding: 1ch 12MP, 4ch 8MP, 8ch 4MP, 16ch 1080P, 32ch D1, 64ch D1
• Dual Stream: Supported
• Multi-screen available: 1st screen: 1/4/8/9/16/32/36/64; 2nd screen: 1/4/8/9/16
• Face comparison: Results of captured and displayed face comparisons in real time (registered (name and ID), stranger, camera, similarity)
• Multi-target: Real-time capture and display of vehicle, person, non-motor vehicle, license plate images and comparison results (registered, stranger, camera, similarity)
• Intelligent search: Time, features, images, license plates
• Alarm actions: Buzzer, alarm push, alarm warning, email, alarm output, simultaneous comparison of results, etc.
• Resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
• Recording mode: Manual, by schedule (normal, continuous), by event
• Event triggering: Motion detection, video loss, alarm input, IVS
• Synchronous playback: 16/9/4/1
• Search mode: Time/date, alarm, image grid, event
• Backup mode: USB device, network, eSATA
• General alarm: Motion detection, video loss, alarm input, alarm output
• Intelligent analysis (on camera): Smoking detection, fire and smoke detection, fire hotspot detection, intrusion, single line crossing, double line crossing, loitering, wrong-way driving, illegal parking, people counting, intelligent motion detection, area entry, area exit, etc.
• Anomaly alarm: Hard drive alarm, IP address conflict, disconnected local network
• Intelligent analysis (on NVR): 4-channel intrusion detection, compatible with precise detection of people and vehicles.
• Alarm actions: Buzzer, mobile app notification, monitor pop-up notification, full screen, email, FTP transfer, PTZ preset, alarm output, recording
• Network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE
• Remote users: 8 users
• P2P: Sunell P2P, Web NAT
• Interoperability: ONVIF, SDK, CGI
• ANR: Supported
• Hard drive grouping: Supported
• RAID: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
• HDD interface: 8 SATA interfaces, up to 16TB capacity per drive
• Network interface: 2 × self-adaptive 10/100/1000Mbps RJ-45 Ethernet ports
• eSATA: 1 eSATA interface
• HDMI: 2
• VGA: 1
• Audio input/output: 1/1
• Alarm input/output: 16/6
• USB interface: Front panel: 2 × USB 2.0, rear panel: 2 × USB 3.0
• RS-485 interface: 1
• RS232 interface: 1
• Reset button: Reset button included
• PoE power: N/A
• Power supply: 100 to 240VAC
• Power consumption: < 15W (without HDD)
• Operating conditions: -10°C to 50°C
• Storage conditions: Less than 90% RH
• Certifications: CE / FCC / NDAA
• Dimensions: 440 × 426 × 111.5mm, 19" 2U rack
• Net weight: 7.3kg without hard drive
• Remote access: Web browser, SunView Smartphone App, SunView PC Software
📦 INCLUDED:
• Sunell NVR Video Recorder• Mouse• Ethernet cable• Instruction manual• Hard drive connection cabling• Power supply
| Range | Pro |
|---|---|
| IP Camera Inputs | 64 channels |
| Incoming Bandwidth | 400Mbps |
| Outgoing Bandwidth | 400Mbps |
| HDMI 1 Output | 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768 |
| HDMI 2 Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
| VGA Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
| Video Decoding | 1ch 12MP, 4ch 8MP, 8ch 4MP, 16ch 1080P, 32ch D1, 64ch D1 |
| Dual Stream | Supported |
| Multi-screen available | 1st screen: 1/4/8/9/16/32/36/64 2nd screen: 1/4/8/9/16 |
| Face Comparison | Real-time captured and displayed face comparison results (registered (name and ID), stranger, camera, similarity) |
| Multi-target | Real-time capture and display of vehicles, people, non-motorized vehicles, license plates, and face comparison results (registered, stranger, camera, similarity) |
| Smart Search | Time, characteristics, images, license plates |
| Alarm Actions | Buzzer, alarm push, alarm alert, email, alarm output, simultaneous result comparison, etc. |
| Resolution | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 |
| Recording Mode | Manual, schedule (normal, continuous), event |
| Event Trigger | Motion detection, video loss, alarm input, IVS |
| Synchronous Playback | 16/9/4/1 |
| Search Mode | Time/date, alarm, image grid, event |
| Backup Mode | USB device, network, eSATA |
| General Alarm | Motion detection, video loss, alarm input, alarm output |
| Smart Analysis (on camera) | Smoking detection, fire and smoke detection, fire focus detection, intrusion, single line crossing, double line crossing, loitering, wrong way driving, illegal parking, people counting, smart motion detection, area entrance, area exit, etc. |
| Anomaly Alarm | Hard disk alarm, IP address conflict, network disconnected |
| Smart Analysis (on NVR) | 4-channel intrusion detection, compatible with precise human and vehicle detection. |
| Alarm Actions | Buzzer, mobile app notification, pop-up notification on monitor, full screen, email, FTP transfer, PTZ preset, alarm output, recording |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE |
| Remote Users | 8 users |
| P2P | Sunell P2P, Web NAT |
| Interoperability | ONVIF, SDK, CGI |
| ANR | Supported |
| HDD Grouping | Supported |
| RAID | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| HDD Interface | 8 SATA interfaces, up to 16TB capacity per drive |
| Network Interface | 2 × self-adaptive 10/100/1000Mbps RJ-45 Ethernet ports |
| eSATA | 1 eSATA interface |
| HDMI | 2 |
| VGA | 1 |
| Audio Input/Output | 1/1 |
| Alarm Input/Output | 16/6 |
| USB Interface | Front panel: 2 × USB 2.0, rear panel: 2 × USB 3.0 |
| RS-485 Interface | 1 |
| RS232 Interface | 1 |
| Reset Button | Reset button included |
| PoE Power | N/A |
| Power Supply | 100 to 240VAC |
| Power Consumption | < 15W (without HDD) |
| Operating Conditions | -10°C to 50°C |
| Storage Conditions | Less than 90% RH |
| Certifications | CE / FCC / NDAA |
| Dimensions | 440 × 426 × 111.5mm, 19" rack 2U |
| Net Weight | 7.3kg without hard drive |
| Remote Access | Web Browser, SunView Smartphone App, SunView PC Software |
