Safire standalone access control - Access via EM card and PIN - Relay output, push button and doorbell - 3
Safire standalone access control - Access via EM card and PIN - Relay output, push button and doorbell - 3
Regular price
€57,65
Final price
Regular price
-4%
€60,00
Sale price
€57,65
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Standalone access control - Access via EM card and PIN - Relay output, button and doorbell - Wiegand 26 - Programmable relay activation time - Suitable for outdoor use IP68
📋 SPECIFICATIONS:
• Brand: Safire
• Model: SF-AC103
• Capacity: Up to 2,000 cards/passwords
• Identification modes: Card, PIN and combinations
• Proximity card: RFID EM 125 kHz
• Outputs: NO/NC relay, button and doorbell
• Communication: Wiegand 26
• Special functions: Operation as standalone terminal or as a reader
• Power supply: DC 12 V
• Standby consumption: ≤ 30 mA
• Protection rating: Outdoor IP68
• Operating temp.: -40 ºC ~ +60 ºC
• Dimensions: 56 (H) x 120 (W) x 20 (D) mm
• Weight: 510 g
📦 INCLUDED:
• Safire standalone access control keypad• Installation material• User instructions
| Model | SF-AC103 |
|---|---|
| Capacity | Up to 2,000 cards/passwords |
| Identification modes | Card, PIN, and combinations |
| Proximity card | RFID EM 125 kHz |
| Outputs | NO/NC relay, push button, and doorbell |
| Communication | Wiegand 26 |
| Special functions | Standalone terminal or reader operation |
| Power supply | 12 V DC |
| Standby consumption | ≤ 30 mA |
| Protection rating | Outdoor IP68 |
| Operating temp. | -40 ºC ~ +60 ºC |
| Dimensions | 56 (H) x 120 (W) x 20 (D) mm |
| Weight | 510 g |
- User manual Link
