Ipertronic

Infrared beam detector

SKU: ABO-20L
(0)
Only 1 left
Stock running low: hurry!
€11,53 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Infrared barrier detector - Wired | 1 beam - Max. detection distance 10 / 20 m - Small size and easy installation - Relay output - Power supply 12~24VDC/VAC

  • Single-beam infrared barrier for outdoor use
  • Wired
  • Maximum transmitter/receiver detection 20 m (indoor) and 10 m (outdoor)
  • Small dimensions
  • Power supply 12-24 VDC/VAC

Data sheet

Detection range 20m indoor / 10m outdoor
Number of beams 1
Detection method Infrared beam interruption
Frequency channels 1 channel
Alarm outputs 1 relay NO/NC (max. 36VDC/VAC, 1A)
Adjustment method Via LED
Operating temperature -25ºC ~ +55ºC
Power supply 12~24 VDC/VAC, 30 mA max.
Dimensions 75.3 (W) x 49.2 (H) x 29.6 (D) mm

Technical features

  • Single-beam infrared barrier for outdoor use
  • Wired, Maximum transmitter detection
  • receiver 20 m (indoor) and 10 m (outdoor)
  • Power supply 12-24 VDC/VAC.

Download user manual (PDF)
Detection range 20m indoor / 10m outdoor
Number of beams 1
Detection method Infrared beam interruption
Frequency channels 1 channel
Alarm outputs 1 relay NO/NC (max. 36VDC/VAC, 1A)
Adjustment method Via LED
Operating temperature -25ºC ~ +55ºC
Power supply 12~24 VDC/VAC, 30 mA max.
Dimensions 75.3 (W) x 49.2 (H) x 29.6 (D) mm
