Ruijie Reyee Cloud Managed L2 Switch - 16-Port High-Speed Gigabit Ethernet RJ45
Ruijie Reyee Cloud Managed L2 Switch - 16-Port High-Speed Gigabit Ethernet RJ45
Regular price
€145,90
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Ruijie Reyee Cloud Managed L2 Switch - 16 High-speed Gigabit Ethernet RJ45 Ports - Intelligent IP Camera (CCTV) Recognition - Automatic Loop Prevention - Forever-free Ruijie Cloud management - V2 version with optimized consumption of only 10W
📋 SPECIFICATIONS:
• Brand: Ruijie Reyee
• Network Interfaces: 16 × 10/100/1000BASE-T RJ45
• Switching Capacity: 32 Gbps
• Packet Forwarding Rate: 23.8 Mpps
• Flash Memory: 8 MB
• MAC Address Table: 8000 entries (supports static configuration)
• Jumbo Frame Size (MTU): 10000 bytes
• VLAN Configuration: IEEE 802.1Q VLAN, LAN port assignment, Max. 16 VLANs
• Smart Network Technology: SON (Self-Organizing Network for automated deployment) and eWeb management
• Video and AI Functions: Automatic IP Camera Recognition, Camera detection
• Recommended Capacity for CCTV systems: Up to 80 2MP (200W) H.265 cameras or 40 4MP (400W) H.265 cameras
• Loop Prevention: Automatic loop prevention (automatic detection and blocking to ensure service continuity)
• Security and Traffic Control: Port isolation, Flow Control, Inbound/Outbound rate limiting per interface
• Storm Protection: Suppression of Broadcast, Multicast, and unknown Unicast
• Network Maintenance: DHCP Client, DNS Client, Port Mirroring, Cable Test (wiring status verification)
• System Security: DHCP Snooping for secure environments, CPU Protection Policy
• Energy Efficiency: Supports IEEE 802.3az (Energy Efficient Ethernet)
• Management Platforms: Forever-free Ruijie Cloud (Web/App), local eWeb (HTTP login), Ruijie Reyee App
• Housing Material: Metal Casing
• Cooling System: Passive, fanless design / Natural cooling
• Mounting Options: Rack mountable (1U height)
• Cable Support: Hot swapping (supported on service ports and power connector)
• Reliability (MTBF): 200,000 hours of continuous operation
• Electrostatic Discharge (ESD) Protection: Air discharge: 8 kV / Contact discharge: 6 kV
• Surge Protection: Service ports: ± 6 kV (common mode) / Power connector: ± 6 kV (common and differential mode)
• Power Supply: Integrated AC power supply (Input: 100-240 V AC, 50/60 Hz, 0.6 A)
• Power Consumption: Maximum 10 W (Optimized V2 efficiency)
• Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F)
• Operating Humidity: 10% to 90% RH (non-condensing)
• Dimensions (W × D × H): 440 mm x 165 mm x 44 mm
• Net Weight: 2.00 kg
📦 INCLUDED:
• 1x Smart Cloud Managed Switch RG-ES216GC-V2
• 2x Metal rack-mount brackets (ears)
• 6x Screws for bracket attachment (M4 x 8 mm)
• 1x AC power cable (1.8 m with cable clip)
• 4x Rubber feet for desktop use
• 1x Quick start guide and user manual
• 1x Official manufacturer warranty certificate
| Network interfaces | 16 × 10/100/1000BASE-T RJ45 |
|---|---|
| Switching capacity | 32 Gbps |
| Packet forwarding rate | 23.8 Mpps |
| Flash memory | 8 MB |
| MAC address table | 8000 entries (supports static configuration) |
| Jumbo Frame size (MTU) | 10000 bytes |
| VLAN configuration | IEEE 802.1Q VLAN, LAN port assignment, Max. 16 VLANs |
| Intelligent network technology | SON (Self-Organizing Network for automatic deployment) and eWeb management |
| Video and AI features | IP Camera Recognition, Camera detection |
| Recommended capacity for CCTV systems | Up to 80 200W (2MP) H.265 cameras or 40 400W (4MP) H.265 cameras |
| Loop prevention | Automatic loop prevention (automatic detection and blocking to ensure service continuity) |
| Security and traffic control | Port isolation, Flow Control, ingress/egress rate limiting per interface |
| Storm protection | Broadcast, Multicast, and unknown Unicast suppression |
| Network maintenance | DHCP Client, DNS Client, Port Mirroring, Cable Test (cable status verification) |
| System security | DHCP Snooping for secure environments, CPU Protection Policy |
| Energy efficiency | Supports IEEE 802.3az (Energy Efficient Ethernet) |
| Management platforms | Ruijie Cloud forever (Web/App), eWeb local (HTTP login), Ruijie Reyee App |
| Housing material | Metal Casing |
| Cooling system | Passive, Fanless design / Natural cooling |
| Mounting options | Rack-mount (1U height) |
| Cable support | Hot swapping (supported on service ports and power connector) |
| Reliability (MTBF) | 200,000 hours of continuous operation |
| Electrostatic Discharge (ESD) protection | Air discharge: 8 kV / Contact discharge: 6 kV |
| Surge protection | Service ports: ± 6 kV (common mode) / Power connector: ± 6 kV (common and differential mode) |
| Power supply | Built-in AC power supply (Input: 100-240 V AC, 50/60 Hz, 0.6 A) |
| Power consumption | Maximum 10 W (V2 optimized efficiency) |
| Operating temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Dimensions (W × D × H) | 440 mm x 165 mm x 44 mm |
| Net weight | 2.00 kg |
