Ruijie Cloud Managed Layer 3 Switch - 28 total ports (24 PoE+ / 4 10G SFP+ Uplinks)
Ruijie Cloud Managed Layer 3 Switch - 28 total ports (24 PoE+ / 4 10G SFP+ Uplinks)
Regular price
€1.430,28
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Ruijie Cloud Managed Layer 3 Switch - 28 Total Ports (24 PoE+ / 4 10G SFP+ Uplinks) - Ultra-fast 10 Gbps fiber optic connections - Dual slot for modular Hot-Swap power supplies - VSU virtualization and advanced L3 redundancy - Free lifetime Ruijie Cloud management
📋 SPECIFICATIONS:
• Brand: Ruijie
• Fixed network interfaces: 24 × 10/100/1000BASE-T PoE/PoE+ RJ45, 4 × 1GE/10GE SFP+ (independent uplink)
• Supported PoE standards: IEEE 802.3af and IEEE 802.3at natively on all copper interfaces
• Maximum PoE power: Up to 740 W (Requires separate purchase of 2 × 600W or 1 × 1000W modular power supplies)
• Maximum power output: Each port provides up to 30 W of stable power per interface
• Pins and delivery mode: Power via Mode A (cable pairs 1-2 and 3-6)
• Fixed management ports: 1 × RJ45 console port, 1 × RJ45 MGMT port, 1 × USB port
• Switching capacity: 128 Gbps
• Packet Forwarding Rate: 96 Mpps
• CPU specifications: Dual-core processor, with each core at a frequency of 1.2 GHz
• System RAM: 1 GB
• Flash Memory / BootROM: Flash: 2 GB / BootROM: 16 MB
• Switch Buffer: 3 MB
• MAC address table: 32,000 entries (enterprise high density)
• L3 table features: ARP table: 4,000 / IPv4 Unicast routes: 8,000 / IPv6 Unicast routes: 4,000 / VLAN conversion: 4,094
• L3 multicast tables: IPv4 Multicast routes: 2,500 / IPv6 Multicast routes: 1,200
• Access Control Lists: ACE filter entries: 3,500 ingress / 1,500 egress
• Device virtualization: VSU (Virtual Switching Unit) technology supporting up to 4 members per logical cluster
• L2 redundancy protocols: STP, RSTP, MSTP and ERPS (G.8032) ring protocol with millisecond convergence
• Routing and IP services: Static routing, RIP, RIPng, OSPFv2/v3, IS-ISv4/v6, BGP4/BGP4+, PBR, VRF, VRRP, DHCP v4/v6
• Cybersecurity ecosystem: CPP (CPU Protect Policy), NFPP, IP Source Guard, SAVI, DHCP Snooping, 802.1X Auth, Web Auth, RPF/URPF
• Quality of Service (QoS): 8 priority queues per interface, classification based on 802.1p/DSCP/ToS, CAR, SP, WRR, DRQ, WFQ, RED, WRED
• Maintenance and diagnostics: RLDP, REUP, DLDP, Port Loop Detection, SPAN/RSPAN/ERSPAN mirroring, sFlow, Syslog, 802.3ah diagnostics
• Management platforms: Ruijie Cloud App/Web, local eWeb, TR-069 CWMP, CLI (Telnet/SSHv1/v2), gRPC, SNMP v1/v2c/v3, RMON
• Energy efficiency: Native support for energy saving on ports (Energy Saving PoE) and integrated circuits
• Chassis structure and format: Metal with conformal coating on key components, 1 RU format
• Power expansion slots: 2 independent modular slots for pluggable power supplies
• Hot maintenance: Native support for hot-swapping cables, optical transceivers, USB units, and power modules
• Fan monitoring: Automatic 3-level dynamic adjustment based on temperature and ventilation failure alarm
• Acoustic noise level: 51.6 dB measured at 27 °C / 58.3 dB at the maximum temperature of 45 °C
• Lightning protection: Contact ESD discharge: 6 kV (8 kV susceptibility) / Air discharge: 8 kV (15 kV susceptibility)
• Surge protection: Service port (Telecom): 10 kV / MGMT port: 4 kV / Power port: 6 kV common and differential mode
• Power consumption: Base power consumption of electronic devices (without PoE): 65 W / Maximum absolute consumption at full load: 810 W
• Environmental conditions: Operating temperature: 0 °C to 45 °C / Humidity: 10% to 90% RH / Altitude: Max. 5,000 m
• Chassis dimensions (W×D×H): 442 mm x 420 mm x 43.6 mm (standard 19-inch rack format)
• Net weight of base chassis: 4.3 kg (9.48 lbs) (Base chassis, excluding external power supply modules)
📦 INCLUDED:
• 1x RG-CS83-24GT4XS-PD L3 Cloud Managed Switch (Base chassis)• 2x Metal rack-mount brackets (ears)• 8x Cross-recessed countersunk head screws (M4x8, GB819-85)• 4x Rubber pads for desktop use• 1x Grounding wire• 1x Mounting bracket installation guide• 1x Warranty manual and substance declaration• (Note: The RG-PA600I-P-F or RG-PA1000I-P-F modular power supplies are not included in the base package and must be purchased separately based on the required PoE power).
| Fixed network interfaces | 24 × 10/100/1000BASE-T PoE/PoE+ RJ45, 4 × 1GE/10GE SFP+ (independent uplink) |
|---|---|
| Supported PoE standards | IEEE 802.3af and IEEE 802.3at natively on all its copper interfaces |
| Maximum PoE power | Up to 740 W (Requires separate purchase of 2 × 600W or 1 × 1000W modular power supplies) |
| Maximum power output | Each port provides up to 30 W of stable power per individual interface |
| Pins and supply mode | Power via Mode A (cable pairs 1-2 and 3-6) |
| Fixed management ports | 1 × RJ45 console port, 1 × RJ45 MGMT port, 1 × USB port |
| Switching capacity | 128 Gbps |
| Packet Forwarding Rate | 96 Mpps |
| CPU specifications | Dual-core processor, with each core at a frequency of 1.2 GHz |
| System RAM | 1 GB |
| Flash Memory / BootROM | Flash: 2 GB / BootROM: 16 MB |
| Switch buffer | 3 MB |
| MAC address table | 32,000 entries (enterprise high density) |
| L3 table functionality | ARP table: 4,000 / IPv4 Unicast routes: 8,000 / IPv6 Unicast routes: 4,000 / VLAN conversion: 4,094 |
| L3 multicast tables | IPv4 Multicast routes: 2,500 / IPv6 Multicast routes: 1,200 |
| Access Control Lists | Filter ACE entries: 3,500 inbound / 1,500 outbound |
| Device virtualization | VSU (Virtual Switching Unit) technology with support for up to 4 members per logical cluster |
| L2 redundancy protocols | STP, RSTP, MSTP, and ERPS ring protocol (G.8032) with millisecond convergence |
| IP routing and services | Static routing, RIP, RIPng, OSPFv2/v3, IS-ISv4/v6, BGP4/BGP4+, PBR, VRF, VRRP, DHCP v4/v6 |
| Cybersecurity ecosystem | CPP (CPU Protect Policy), NFPP, IP Source Guard, SAVI, DHCP Snooping, 802.1X Auth, Web Auth, RPF/URPF |
| Quality of Service (QoS) | 8 priority queues per interface, classification based on 802.1p/DSCP/ToS, CAR, SP, WRR, DRQ, WFQ, RED, WRED |
| Maintenance and diagnostics | RLDP, REUP, DLDP, Port Loop Detection, SPAN/RSPAN/ERSPAN mirroring, sFlow, Syslog, 802.3ah diagnostics |
| Management platforms | Ruijie Cloud App/Web, local eWeb, TR-069 CWMP, CLI (Telnet/SSHv1/v2), gRPC, SNMP v1/v2c/v3, RMON |
| Energy efficiency | Native support for port power saving (Energy Saving PoE) and integrated circuits |
| Chassis structure and format | Metal with conformal coating on key components, 1 RU format |
| Power expansion slots | 2 independent modular slots for pluggable power supplies |
| Hot maintenance | Native support for hot-swapping cables, optical transceivers, USB units, and power modules |
| Fan monitoring | Automatic 3-level dynamic adjustment based on temperature and ventilation failure alarm |
| Acoustic noise level | 51.6 dB measured at 27 °C / 58.3 dB at the maximum temperature of 45 °C |
| Lightning protection | Contact ESD: 6 kV (8 kV susceptibility) / Air discharge: 8 kV (15 kV susceptibility) |
| Surge protection | Service port (Telecom): 10 kV / MGMT port: 4 kV / Power port: 6 kV common and differential |
| Electric power consumption | Base power consumption of electronic devices (without PoE): 65 W / Absolute maximum consumption at full load: 810 W |
| Environmental conditions | Operating temperature: 0 °C to 45 °C / Humidity: 10% to 90% RH / Altitude: Max. 5,000 m |
| Chassis dimensions (W×D×H) | 442 mm x 420 mm x 43.6 mm (standard 19-inch rack format) |
| Net weight of base chassis | 4.3 kg (9.48 lbs) (Base chassis, excluding external power modules) |
