Ruijie central card for large-scale trunk connections
Ruijie central card for large-scale trunk connections
Regular price
€10.899,24
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Ruijie Core board for large-scale trunk connections - 8 independent 40GE/100GE QSFP28 core slots - Multi-port MPO optical connectors and LC cables - Maximum bandwidth for data centers and backbones - Full hot-swap support for service ports
📋 SPECIFICATIONS:
• Brand: Ruijie
• Board model: CM88-8CQ-H
• Chassis compatibility: Designed exclusively for RG-CS88 series modular chassis (RG-CS88-08)
• Fiber optic ports (maximum speed): 8 × independent 40GE/100GE QSFP28 (Supports actual 40G and 100G speeds)
• Optical connector type: MPO 1x12 (for SR/LSR short-range transceivers) and Duplex LC (for LR4/iLR4 transceivers)
• Active cable support: Fully compatible with 100G active optical cables (AOC) (5m and 10m), as well as 40G AOC cables (5m and 30m)
• Core-level performance: Designed for large-scale backbones, main inter-chassis links, and data center aggregation
• Per-port QoS policy: 8 priority queues per port with Tail Drop, RED, and WRED congestion management algorithms
• Access control mechanisms: Support for standard, extended, expert-level, and global per-port hardware ACLs at ultra-high speed
• Hot-Swap: Native support for hot-swapping high-performance transceivers and active optical cables
• Airflow and cooling: Lateral aerodynamic design coordinated with the base chassis ventilation system
• Structure material: Industrial-grade rigid metal frame (CS88 card slot format)
• Manufacturer warranty: 5 years (in line with main chassis warranty terms)
📦 INCLUDED:
• 1x 100G QSFP28 Core line card CM88-8CQ-H
| Card model | CM88-8CQ-H |
|---|---|
| Chassis compatibility | Designed exclusively for RG-CS88 series modular chassis (RG-CS88-08) |
| Fiber optic ports (maximum speed) | 8 × 40GE/100GE independent QSFP28 (Supports actual 40G and 100G speeds) |
| Optical connector type | MPO 1x12 (for SR/LSR short-range transceivers) and Duplex LC (for LR4/iLR4 transceivers) |
| Active cable support | Fully compatible with 100G active optical cables (AOC) (5m and 10m), as well as 40G AOC cables (5m and 30m) |
| Core-level performance | Designed for large-scale backbones, main chassis-to-chassis links, and data center aggregation |
| Per-port QoS policy | 8 priority queues per port with Tail Drop, RED, and WRED congestion management algorithms |
| Access control mechanisms | Support for ultra-high-speed standard, extended, expert-level, and global per-port hardware ACLs |
| Hot-Swap | Native support for hot-swapping high-performance transceivers and active optical cables |
| Airflow and cooling | Lateral aerodynamic design coordinated with the base chassis ventilation system |
| Frame material | Industrial-grade rigid metal frame (CS88 card slot format) |
| Manufacturer warranty | 5 years (in line with the main chassis warranty terms) |
