Reyee e-Lighten PoF Cable
Regular price
€446,00
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Reyee e-Lighten - PoF Cable - Hybrid cable for simultaneous data and power transmission. - Rated voltage class up to 150V. - Flat design optimized for indoor installations. - Expected lifespan of over fifteen years.
📋 SPECIFICATIONS:
• Brand: Reyee e-Lighten
• Cable Type: Hybrid optical-electrical (PoF)
• Application: Indoor
• Rated voltage: 150V
• Expected lifespan: ≥ 15 years
• Fiber Type: Single-mode silica (G.657A2)
• Fiber count: 2 Cores
• Optical attenuation: ≤ 0.36 dB/km @1310 nm / ≤ 0.25 dB/km @1550 nm
• Max resistance. Cond.: 92.3 Ω/km (0.2 mm²) / 39 Ω/km (0.5 mm²)
• Insulation Resistance: ≥ 0.013 MΩ·km
• Operating Temperature: -20 °C to 70 °C
• Max tensile load: 200 N (Short term) / 100 N (Long term)
• Crush resistance: 1,000 N / 100 mm (Short term)
• Flame retardancy: Compliant with GB/T 18380.12 standard
• Environmental protection: RoHS 2.0
📦 INCLUDED:
• 1x Ruijie Reyee hybrid cable spool (305m) • 1x Certificate of conformity and quality test report
| Cable Type | Hybrid optical-electrical (PoF) |
|---|---|
| Application | Indoor |
| Rated Voltage | 150V |
| Service Life | ≥ 15 years |
| Fiber Type | Single-mode silica (G.657A2) |
| Fiber Count | 2 Cores |
| Optical Attenuation | ≤ 0.36 dB/km @1310 nm / ≤ 0.25 dB/km @1550 nm |
| Max. Conductor Resistance | 92.3 Ω/km (0.2 mm²) / 39 Ω/km (0.5 mm²) |
| Insulation Resistance | ≥ 0.013 MΩ·km |
| Operating Temperature | -20 °C to 70 °C |
| Max. Tensile Load | 200 N (Short-term) / 100 N (Long-term) |
| Crush Resistance | 1,000 N / 100 mm (Short-term) |
| Flame Retardancy | Complies with GB/T 18380.12 standard |
| Environmental Protection | RoHS 2.0 |
