Reyee Wireless bridge up to 867Mbps - Wireless connection up to 15 km - Gigabit Ethernet port
Reyee Wireless bridge up to 867Mbps - Wireless connection up to 15 km - Gigabit Ethernet port
Regular price
€117,00
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Reyee Wireless bridge up to 867Mbps - Wireless link up to 15 km - 5 GHz 5.85 GHz frequency - Proprietary TDMA-based protocol - IP65, suitable for outdoor use - Gigabit Ethernet port
📋 SPECIFICATIONS:
• Brand: Reyee
• Wireless Standard: Proprietary
• Operating mode: Point-to-Point / Point-to-Multipoint (up to 32 CPEs)
• RJ45 Port: 10/100/1000 Mbps
• Frequencies: 5GHz – 5.85 GHz
• Distance: Up to 15 km
• Channel width: 20/40/80MHz
• Transmission range: 0 to +26 dBm
• Integrated antenna: 23 dBi Dual directional
• TDMA: Fixed Mode / Flexible Mode
• Management: Web interface configuration, One-click configuration, AI Heatmap for wireless bridge, Bridge alignment tool, Spectrum scan and Link optimization
• Additional features: SSID masking, Spectrum analysis, Alignment tools, One-Touch Pairing, WMM, Storm Control, VLAN Packet Transmit, DHCP Server, Network Diagnoses Ping/Trace Route/DNS, ARQ
• Power supply: 24 VDC non-standard PoE
• Operating temperature: -40°C ~ 70°C (When using the power adapter, the maximum operating temperature of the device and power adapter is 60° max)
• Electrostatic protection: ±24 kV Contact/Air
• Surge protection: 6 kV
• IP Rating: IP65
• Power consumption: < 12 W
• Dimensions (Diameter x Length, including mounting kit): 368.5 x 271 mm
• Weight: 2.33 kg
📦 INCLUDED:
• 1 x RG-AirMetro460G• 1 x Passive PoE injector• Pole mounting accessory kit with metal flanges• Instructions
| Wireless Standard | Proprietary |
|---|---|
| Operating Mode | Point-to-Point / Point-to-Multipoint (up to 32 CPEs) |
| RJ45 Port | 10/100/1000 Mbps |
| Frequencies | 5GHz – 5.85 GHz |
| Distance | Up to 15 km |
| Channel Width | 20/40/80 MHz |
| Transmission Range | 0 to +26 dBm |
| Integrated Antenna | 23 dBi Dual-directional |
| TDMA | Fixed Mode / Flexible Mode |
| Management | Web-based interface configuration, One-click configuration, AI Heatmap for wireless bridge, Bridge alignment tool, Spectrum scan and link optimization |
| Additional Features | SSID masking, Spectrum analysis, Alignment tools, One-Touch Pairing, WMM, Storm Control, VLAN Packet Transmit, DHCP Server, Network Diagnoses Ping/Trace Route/DNS, ARQ |
| Power Supply | 24 VDC non-standard PoE |
| Operating Temperature | -40 °C ~ 70 °C (When using the power adapter, the maximum operating temperature of the device and power adapter is 60° max) |
| Electrostatic Protection | ±24 kV Contact/Air |
| Surge Protection | 6 kV |
| IP Rating | IP65 |
| Power Consumption | < 12 W |
| Dimensions (Diameter x Length, including mounting kit) | 368.5 x 271 mm |
| Weight | 2.33 kg |
