RAEDIAN

Raedian Smart Meter Compatible with NEO - Three-phase | Up to 200A

SKU: RD-SCK-3P-3CT
(0)
Only 2 left
Stock running low: hurry!
€133,73 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Raedian Smart Meter - Compatible with NEO - Three-phase | Up to 200A - Bidirectional - DIN rail mounting - Class I accuracy

📋 SPECIFICATIONS:
• Brand: RAEDIAN
• Device type: Bidirectional Smart Meter
• Rated voltage: Three-phase 230/400Vac
• Power consumption: <0.2 W
• Power measurement: Active, reactive, apparent
• Input current: 200A with 200A clamps included
• Mains frequency: 45-65 Hz
• Accuracy class: Class I +-0.5%
• Mounting: DIN rail
• Measurement: Class B (split-core current transformer)
• Operating temperature: -40 ~ 70ºC
• Communication: RS485 interface and Modbus RTU protocol (1-247)
• Baud rate: 1200bps - 38400bps
• Compatibility: NEO 11 and 22 kW chargers (Three-phase)
• Color: White
• Dimensions: 65 (H) x 90 (W) x 45 (D) mm
• CT hole size: 24 mm
• Overload: x1.2 continuous; x2 for 1s
• Response time: <100ms (voltage, current, power); <1s (electrical energy)
• Operating temperature: -40ºC - 70ºC
• Relative humidity: <95% (non-condensing)
• Altitude: Up to 3000m

📦 INCLUDED:
• Smart Meter• 3x 200A CT Clamp
Device type Bidirectional Smart Meter
Rated voltage Three-phase 230/400Vac
Consumption &lt;0.2 W
Power measurement Active, reactive, apparent
Input current 200A with 200A clamps included
Grid frequency 45-65 Hz
Accuracy class Class I +-0.5%
Mounting DIN rail
Measurement Class B (split-core current transformer)
Operating temperature -40 ~ 70ºC
Communication RS485 interface and Modbus RTU protocol (1-247)
Baud rate 1200bps - 38400bps
Compatibility NEO 11 and 22 KW chargers (Three-phase)
Color White
Dimensions 65 (H) x 90 (W) x 45 (D) mm
CT hole size 24 mm
Overload x1.2 continuous, x2 for 1s
Response time &lt;1s (electrical energy)
Working temperature -40ºC - 70ºC
Relative humidity &lt;95% (non-condensing)
Altitude Up to 3000m
