Queclink compact BLE relay
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
BLE Relay - Compact dimensions - Easy installation - IP64 - BLE 5.1 - Remote control
📋 SPECIFICATIONS:
• Brand: Queclink
• Model: WRL300
• Waterproof: IP64
• Dimensions: 49mm x 27mm x 16mm
• Weight: 22g
• Operating voltage: 8 ~ 32V DC
• Standby consumption: < 1.5mA @12V; < 1mA @24V
• Active consumption: 19mA@12V / 10.6mA@24V
• Maximum load: 6A@250VAC / 6A@30VDC
• Maximum voltage: 400VAC/125VDC
• Maximum consumption: 6A
• Operating temperature: -40 ~ +85 ℃
• Transmission range: Up to 80m (in open field)
| Model | WRL300 |
|---|---|
| Waterproof | IP64 |
| Dimensions | 49mm x 27mm x 16mm |
| Weight | 22g |
| Operating voltage | 8 ~ 32V DC |
| Standby consumption | < 1.5mA @12V; < 1mA @24V |
| Active consumption | 19mA@12V / 10.6mA@24V |
| Maximum load | 6A@250VAC / 6A@30VDC |
| Maximum voltage | 400VAC/125VDC |
| Maximum current | 6A |
| Operating temperature | -40 ~ +85 ℃ |
| Transmission range | Up to 80m (in open field) |
Same-day shipping if you order before 12:00 PM! In most cases, we rely on couriers with 24-hour service so your order arrives on time.
For orders under €200, the shipping fee is €15.90. For deliveries to remote areas or islands, couriers apply a surcharge to cover transport costs.
The legal warranty lasts 2 years for private individuals (consumers) and 1 year for VAT holders (professionals or companies)
