Queclink low-power mini tracker
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Low-power mini tracker - LTE Cat 1 with 2G backup - Compact for hidden installations - Supports 1-wire - BLE 5.2
📋 SPECIFICATIONS:
• Brand: Queclink
• Model: GV58CEU
• Installation: Hardwired connection
• Operating band: LTE-FDD: B1/B3/B7/B8/B20/B28
• LTE data transmission: LTE-FDD: (DL) 10Mbps /(UL) 5Mbps
• Frequency: 900/1800 MHz
• EGPRS data transmission: EDGE: (DL) 236.8Kbps (DL)/ (UL) 236.8Kbps; GPRS: (DL) 85.6Kbps/(UL) 85.6Kbps
• GNSS type: u-blox all-in-one GNSS receiver
• Positioning: GPS, Glonass, Galileo, Beidou
• Sensitivity: Cold start: -148 dBm; Hot start: -160 dBm; Tracking: -167dBm
• Position accuracy (CEP): Standalone: <2.0m
• TTFF: Cold start: 24s approx.; Hot start: 1s approx.
• Dimensions: 86.7(L) x 46.4(W) x 18.1(H)
• Weight: 80g
• Backup battery: Lithium polymer, 190 mAh
• Power supply: 8V to 32V DC
• Operating temperature: -30ºC ~ +70ºC; -40ºC ~ +80ºC for storage
• BLE: Supports BLE 5.2 protocol
• Digital inputs: x1 positive trigger input for ignition detection; x2 negative trigger inputs (1 configurable as digital/analog input)
• Digital output: x1 digital output, normally open, max consumption 150 mA
• Latched digital output: 1x digital output with internal latch, normally open, max consumption 150 mAh (Reserved)
• Cellular antenna: Internal only
• GNSS antenna: Internal only
• BLE antenna: Internal only
• LED indicators: CEL, GNSS, Power
• Micro USB interface: For update and debugging
• 1-Wire interface: x1 (supports 1-wire temperature sensors and iButton readers)
• Transmission protocol: TCP, UDP, SMS
• Scheduled reports: Positioning and status based on time intervals, distance, mileage, or a combination of these parameters
• Geo-fence: Geo-fence and parking alarm, supports up to 20 regions
• Low battery alarm: Alerts when the backup battery is low
• Power-on report: Reports when the device powers on
• Towing alarm: Notification of towing event when device is powered off
• Driving behavior monitoring: Aggressive driving detection, including harsh braking, acceleration, etc.
• Crash detection: Accident data collection for reconstruction and analysis
• Special alarm: Special alarms based on digital inputs/outputs
• Remote control: OTA control of digital outputs
📦 INCLUDED:
• Device only
| Model | GV58CEU |
|---|---|
| Installation | Hardwired connection |
| Operating band | LTE-FDD: B1/B3/B7/B8/B20/B28 |
| LTE data transmission | LTE-FDD: (DL) 10Mbps /(UL) 5Mbps |
| Frequency | 900/1800 MHz |
| EGPRS data transmission | EDGE: (DL) 236.8Kbps (DL)/ (UL) 236.8Kbps GPRS: (DL) 85.6Kbps/(UL) 85.6Kbps |
| GNSS type | u-blox all-in-one GNSS receiver |
| Positioning | GPS, Glonass, Galileo, Beidou |
| Sensitivity | Cold start: -148 dBm Hot start: -160 dBm Tracking: -167dBm |
| Positioning accuracy (CEP) | Standalone: <2.0m |
| TTFF | Cold start: approx. 24s Hot start: approx. 1s |
| Dimensions | 86.7(L) x 46.4(W) x 18.1(H) |
| Weight | 80g |
| Backup battery | Lithium-polymer, 190 mAh |
| Power supply | 8V to 32V DC |
| Operating temperature | -30ºC ~ +70ºC -40ºC ~ +80ºC for storage |
| BLE | Supports BLE 5.2 protocol |
| Digital inputs | x1 positive trigger input for ignition detection x2 negative trigger inputs (1 configurable as digital/analog input) |
| Digital output | x1 digital output, normally open, 150 mA max current |
| Locked digital output | x1 digital output with internal locking, normally open, 150 mA max current (Reserved) |
| Cellular antenna | Internal only |
| GNSS antenna | Internal only |
| BLE antenna | Internal only |
| LED indicators | CEL, GNSS, Power |
| Micro USB interface | For update and debugging |
| 1-wire interface | x1 (supports temperature sensors and 1-wire iButton readers) |
| Transmission protocol | TCP, UDP, SMS |
| Scheduled reports | Positioning and status based on time intervals, distance, mileage, or a combination of these parameters |
| Geo-fence | Geo-fence and parking alarm, supports up to 20 regions |
| Low battery alarm | Alerts when the backup battery is low |
| Power-on report | Reports when the device is powered on |
| Towing alarm | Notifies of a towing event when in power-off state |
| Driver behavior monitoring | Aggressive driving detection, including harsh braking, acceleration, etc. |
| Collision detection | Collection of accident data for reconstruction and analysis |
| Special alarm | Special alarms based on digital inputs/outputs |
| Remote control | OTA control of digital outputs |
