Queclink LTE Cat 1 with 2G fallback
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
LTE Cat 1 with 2G backup - 9 to 90 V input voltage range - Compact size
📋 SPECIFICATIONS:
• Brand: Qeclink
• Model: GV50CG
• Installation: Hidden under the hood
• Operating band: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
• LTE data transmission: LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
• Frequency: 850/900/1800/1900 MHz
• GSM data transmission: EDGE: (DL)236.8 Kbps/(UL)236.8 Kbps; GPRS: (DL)85.6 Kbps/(UL)85.6 Kbps
• GNSS type: All-in-one GNSS receiver
• Supported constellations: GPS, Beidou
• Sensitivity: Cold start: -147dBm; Warm start: -155 dBm; Tracking: -160 dBm
• Location accuracy (CEP): Autonomous: < 2m
• Time to First Fix (TTFF) - open sky: Cold start: approx. 28 seconds; Warm start: approx. 1 second
• Dimensions: 76(L) × 39(W) × 16(H) mm
• Weight: 71.5g
• Backup battery: Lithium polymer, 190 mAh
• Operating voltage: 9V ~ 90V DC
• Operating temperature: -30℃ ~ +70℃; -40℃ ~ +80℃ for storage
• Message buffer: Up to 10,000 messages
• Digital inputs: One (1) positive trigger input for ignition detection
• Configurable inputs: One (1) configurable input for analog input (0 ~ 16V) or negative input
• Latched digital output: One (1) latched digital output, open drain, with 150 mA maximum drive current
• GSM antenna: Internal only
• GNSS antenna: Internal only
• LED indicators: CEL, GNSS
• Micro USB interface: For configuration, upgrading, and debugging
• Transmission protocol: TCP, UDP, SMS
• Scheduled report: Reports position and status based on preset time intervals, distance, mileage, or a combination of these settings
• Geo-fence: Geo-fence and parking alarm, supports up to 20 areas
• Speed alarm: Flexible speed monitoring, with abnormal speed alarm
• Low battery alarm: Alarm notification when the battery is low
• Towing alarm: Towing alarm in deactivated state
• Driver behavior: Detects aggressive driving behavior, including harsh braking, harsh acceleration, etc.
• Crash detection: Collects accident data for reconstruction and analysis
• Remote control: OTA control on digital output
• SOS alarm: Alarm message report triggered by emergency button
• Virtual ignition detection: Based on voltage and accelerometer
• Jamming detection: Alarm based on jamming detection
📦 INCLUDED:
• Device only
| Model | GV50CG |
|---|---|
| Installation | Hidden under the hood |
| Operating Band | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| LTE data transmission | LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL) |
| Frequency | 850/900/1800/1900 MHz |
| GSM data transmission | EDGE: (DL) 236.8 Kbps/(UL) 236.8 Kbps GPRS: (DL) 85.6 Kbps/(UL) 85.6 Kbps |
| GNSS Type | All-in-one GNSS receiver |
| Supported constellations | GPS, Beidou |
| Sensitivity | Cold start: -147dBm Hot start: -155 dBm Tracking: -160 dBm |
| Location accuracy (CEP) | Autonomous: < 2m |
| Time to First Fix (TTFF) - open field | Cold start: approx. 28 seconds Hot start: approx. 1 second |
| Dimensions | 76(W) × 39(D) × 16(H) mm |
| Weight | 71.5g |
| Backup battery | Lithium polymer, 190 mAh |
| Operating voltage | 9V ~ 90V DC |
| Operating temperature | -30℃ ~ +70℃ -40℃ ~ +80℃ for storage |
| Message buffer | Up to 10,000 messages |
| Digital inputs | One (1) positive trigger input for ignition detection |
| Configurable inputs | One (1) configurable input for analog input (0 ~ 16V) or negative input |
| Bistable digital output | One (1) bistable digital output, open drain, with 150 mA maximum sink current |
| GSM antenna | Internal only |
| GNSS antenna | Internal only |
| LED indicators | CEL, GNSS |
| Micro USB interface | For configuration, upgrade and debugging |
| Transmission protocol | TCP, UDP, SMS |
| Scheduled report | Report location and status based on preset time intervals, distance, mileage, or a combination of these configurations |
| Geo-fence | Geo-fence and parking alarm, supports up to 20 areas |
| Speeding alarm | Flexible speed monitoring, with abnormal speed alarm |
| Low battery alarm | Alarm notification when the battery is low |
| Tow alarm | Towing alarm in disarmed state |
| Driver behavior | Detects aggressive driving behavior, including harsh braking, harsh acceleration, etc. |
| Crash detection | Collects accident data for reconstruction and analysis |
| Remote control | OTA control on digital output |
| SOS alarm | Alarm message report triggered by emergency button |
| Virtual Ignition Detection | Based on voltage and accelerometer |
| Jamming detection | Alarm based on jamming detection |
