Queclink LTE Cat 1 OBD mini tracker
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Mini OBD LTE Cat 1 tracker - Compact dimensions - Supports BLE 5.2 - Ideal for vehicle leasing
📋 SPECIFICATIONS:
• Brand: Queclink
• Model: GV500CG
• Installation: OBD port
• Operating band: Cat 1: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
• LTE data transmission: LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
• Operating frequency: GSM850/GSM900/GSM1800/GSM1900
• GSM data transmission: GPRS:(DL)85.6Kbps/(UL)85.6Kbps; EDGE:(DL)236.8Kbps/(UL)236.8Kbps
• GNSS type: All-in-one GNSS receiver
• Sensitivity: Autonomous: -147 dBm; Hot start: -163 dBm; Reacquisition: -160 dBm; Tracking: -165 dBm
• Positioning accuracy (CEP): Autonomous: < 2.0m
• TTFF (open sky): Cold start: 24s average; Warm start: 24s average; Hot start: 1s average
• Dimensions: 50(W) x 46(H) x 23(D)
• Weight: 41g
• Battery: Li-Polymer, 3.7V, 60mAh
• Operating voltage: 8V ~ 32V DC
• Operating temperature: -20 ℃ ~ +60 ℃; -40 ℃ ~ +80 ℃ (storage)
• Message buffer: Up to 10,000 messages
• BLE: Supports BLE 5.2
• GSM antenna: Internal only
• GPS antenna: Internal only
• LED indicators: CELL, GNSS, PWR
• Micro USB: Port for configuration and FW update
• OBD: For power supply only
• Transmission protocols: TCP, UDP, SMS
• Programmable reports: Reports position and status based on time intervals, distance, mileage, or a combination of these settings.
• Geo-fence: Geo-fence alarm, parking, supports up to 20 areas
• Battery report: Low battery notification
• Ignition report: Notification when the device is turned on/off
• Towing alarm: Notification when the vehicle is towed even if the engine is off
• Jamming detection: Alarm based on interference detection
• Virtual ignition detection: Based on voltage and accelerometer
• Driver monitoring: Monitors aggressive behavior, including harsh braking, acceleration, etc...
• Collision detection: Collects information for accident reconstruction and analysis
• Motion detection: Motion alarm based on internal 3-axis accelerometer
• MQTT: Data reporting to MQTT server
• TLS: Supports TLS1.2 encryption
📦 INCLUDED:
• Device only
| Model | GV500CG |
|---|---|
| Installation | OBD port |
| Operating band | Cat 1: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| LTE data transmission | LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL) |
| Operating frequency | GSM850/GSM900/GSM1800/GSM1900 |
| GSM data transmission | GPRS:(DL)85.6Kbps/(UL)85.6Kbps EDGE:(DL)236.8Kbps/(UL)236.8Kbps |
| GNSS type | All-in-one GNSS receiver |
| Sensitivity | Autonomous: -147 dBm Hot start: -163 dBm Reacquisition: -160 dBm Tracking: -165 dBm |
| Position accuracy (CEP) | Autonomous: < 2.0m |
| TTFF (open sky) | Cold start: ~24s Warm start: ~24s Hot start: ~1s |
| Dimensions | 50(W) x 46(H) x 23(D) |
| Weight | 41g |
| Battery | Lithium polymer, 3.7 V, 60 mAh |
| Operating voltage | 8V ~ 32V DC |
| Operating temperature | -20 ℃ ~ +60 ℃ -40 ℃ ~ +80 ℃ (storage) |
| Message buffer | Up to 10000 messages |
| BLE | Supports BLE 5.2 |
| GSM antenna | Internal only |
| GPS antenna | Internal only |
| LED indicators | CELL, GNSS, PWR |
| Micro USB | Port for configuration and FW upgrade |
| OBD | Power only |
| Transmission protocols | TCP, UDP, SMS |
| Programmable reports | Report position and status based on time intervals, distance, mileage, or a combination of these settings. |
| Geo-fence | Geo-fence alarm, parking, supports up to 20 areas |
| Battery report | Low battery notification |
| Power-on report | Notification when the device is powered on/off |
| Tow alarm | Notification when the vehicle is towed even if the engine is off |
| Jamming detection | Alarm based on interference detection |
| Virtual ignition detection | Based on voltage and accelerometer |
| Driver monitoring | Monitors aggressive behavior, including harsh braking, acceleration, etc... |
| Crash detection | Collects information for accident reconstruction and analysis |
| Motion detection | Motion alarm based on internal 3-axis accelerometer |
| MQTT | Data reporting to MQTT server |
| TLS | Supports TLS1.2 encryption |
