Global LTE Cat M1/NB2 with 2G with a single Queclink antenna - Supports wireless charging
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Global LTE Cat M1/NB2 with 2G with a single antenna - Battery life up to 7 years - Supports wireless charging - Waterproof, IP67 compliant - Quick and flexible installation - Ideal for asset tracking and lot management
📋 SPECIFICATIONS:
• Brand: Queclink
• Model: GL521MG
• Installation: Flexible
• Operating band: LTE Cat M1/NB2; Cat M1:; B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/; B27/B28/B66/B85; Cat NB2:; B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/; B28/B66/B71/B85
• LTE data transmission: eMTC (DL) 348kbps; eMTC (UL) 1.08Mbps; NB2 (DL) 121kbps; NB2 (UL) 150kbps; NB1 (DL) 74.1kbps; NB1 (UL) 101kbps
• Operating frequency: EGPRS 850/900/1800/1900 MHz
• EGPRS data transmission: GPRS 107 Kbps(DL)/ 85.6 Kbps(UL); EDGE 296 Kbps(DL)/ 236.8 Kbps(UL
• Dimensions: 87(W) × 51(D) × 30(H)mm; 87(W) × 51(D) × 33.5(H)mm; (version for magnetic case mounting)
• Weight: 140 g; 160 g; (version for magnetic case mounting)
• Backup battery: 3 CR123A lithium batteries, 1,400 mAh
• Lifespan: 1 report per day (GNSS enabled): 5 years; 1 report per day (cell ID only): 7 years
• Protection rating: IP67 compliant
• Operating temperature: -20℃ ~ +60℃
• Internal temperature sensor: To monitor temperature; Accuracy: ±1℃
• Internal light sensor: For tamper detection
• Vibration: For confirmation signal when pressing a function button
• Magnetic Mount Case (Optional): For easy installation on metal surfaces
• GNSS type: All-in-one u-blox GNSS receiver
• Constellations: GPS, Glonass, Galileo, Beidou
• GNSS sensitivity: Cold start: -148dBm; Hot start: -160 dBm; Tracking: -167 dBm
• Positioning accuracy (CEP): Autonomous: < 2m
• Time to first fix (TTFF) - open sky: Cold start: approx. 24s; Hot start: approx. 1s
• Function button: Used for power on/off and checking operating status
• LTE antenna: Internal only
• GNSS antenna: Internal only
• LED indicators: GNSS, Status
• Commands: Queclink protocol commands
• Transmission protocol: TCP, UDP, SMS
• Working modes: Power saving mode for extended standby time; Continuous mode for emergency monitoring
• Scheduled report: Position and status notification at preset time intervals
• Geo-fence: Supports up to 20 areas
• Battery alarm: Alarm when the internal battery is low
• Wake-up report: Notification when the device is activated
• Motion detection: Motion detection based on internal 3-axis accelerometer
• Report frequency setting: Intelligent report frequency setting
📦 INCLUDED:
• Device• Serial number sticker• Screws• Double-sided tape
| Model | GL521MG |
|---|---|
| Installation | Flexible |
| Operating Band | LTE Cat M1/NB2 Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/ B27/B28/B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/ B28/B66/B71/B85 |
| LTE Data Transmission | eMTC (DL) 348kbps eMTC (UL) 1.08Mbps NB2 (DL) 121kbps NB2 (UL) 150kbps NB1 (DL) 74.1kbps NB1 (UL) 101kbps |
| Operating Frequency | EGPRS 850/900/1800/1900 MHz |
| EGPRS Data Transmission | GPRS 107 Kbps(DL)/ 85.6 Kbps(UL) EDGE 296 Kbps(DL)/ 236.8 Kbps(UL) |
| Dimensions | 87(W) × 51(D) × 30(H)mm 87(W) × 51(D) × 33.5(H)mm (magnetic housing version) |
| Weight | 140 g 160 g (magnetic housing version) |
| Backup Battery | 3 x CR123A lithium batteries, 1,400 mAh |
| Battery Life | 1 report per day (GNSS enabled): 5 years 1 report per day (Cell ID only): 7 years |
| Ingress Protection | IP67 compliant |
| Operating Temperature | -20℃ ~ +60℃ |
| Internal Temperature Sensor | For temperature monitoring Accuracy: ±1℃ |
| Internal Light Sensor | For tamper detection |
| Vibration | For confirmation signal when a function button is pressed |
| Magnetic Housing (Optional) | For easy installation on metal surfaces |
| GNSS Type | u-blox all-in-one GNSS receiver |
| Constellations | GPS, Glonass, Galileo, Beidou |
| GNSS Sensitivity | Cold start: -148dBm Hot start: -160 dBm Tracking: -167 dBm |
| Location Accuracy (CEP) | Autonomous: < 2m |
| Time to First Fix (TTFF) - open sky | Cold start: ~24s Hot start: ~1s |
| Function Button | Used for power on/off and operation status check |
| LTE Antenna | Internal only |
| GNSS Antenna | Internal only |
| LED Indicators | GNSS, Status |
| Commands | Queclink protocol commands |
| Transmission Protocol | TCP, UDP, SMS |
| Operating Modes | Power saving mode for long standby time Continuous mode for emergency monitoring |
| Scheduled Report | Position and status reporting at preset intervals |
| Geo-fence | Supports up to 20 internal geo-fence regions |
| Battery Alarm | Alarm when the internal battery is low |
| Wake-up Report | Notification when the device is triggered |
| Motion Detection | Motion detection based on internal 3-axis accelerometer |
| Report Frequency Setting | Intelligent reporting frequency setting |
