Nivian Smart Outdoor Volumetric Detector - Detection range 6~9m/110º [%VAR%]
Nivian Smart Outdoor Volumetric Detector - Detection range 6~9m/110º [%VAR%]
Regular price
€26,51
Final price
Regular price
-12%
€30,00
Sale price
€26,51
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Nivian Smart - Outdoor volumetric detector - Detection range 6~9m/110º [%VAR%] - LED indicator - 433MHz wireless - Compatible with all Nivian alarm panels
📋 SPECIFICATIONS:
• Brand: Nivian
• Model: NVS-OUTDOORPIR
• Range: Smart Security - Intrusion alarm peripherals
• Device type: Wireless pet-immune outdoor presence detector
• Functions: Presence detection - Signals the presence of people to the alarm panel when the system is armed
• Technology: Passive infrared (PIR) volumetric sensor - Detects motion when a body with a temperature similar to the human body crosses the sensor beams - Outdoor temperature compensation (reduces false alarms) - White light filter + Sunshield (reduces sunlight interference) - Dual infrared optics immune to pets - Standby mode (reduces redundant alarms and saves energy) - Tamper alarm
• Range: Average range 6~9 m - Effective detection angle 110° - Applicable to an estimated area of 12 x 12 m - Immune to pets with dimensions similar to animals < 20Kg - Detection time in standby mode 5s or 3 min
• Visual indicator: LED detection indicator - Low battery warning - Walk test indicator
• Wireless communication with alarm panel: 433 MHz RF radio - Range up to 150 m in open space
• Alarm modes configurable with the alarm panel: Detection in total or perimeter activation mode (home mode)
• Compatibility: Nivian alarm kits with 433 MHz wireless frequencies
• Installation: Wall mounting (bracket included) - Recommended height 2~2.4 m (do not install at < 1.5 m) - Idle time setting after first detection 5s or 3min via rear switch - Walk test function to check for correct installation
• Power supply: 2 x AA batteries - Standby consumption: ≤8μA - Alarm consumption ≤10mA
• Material: ABS plastic housing and IR polycarbonate optics
• Operating temperature: -20°C~50°C
• Environmental protection: Suitable for indoor and outdoor use
• Dimensions: 120 x 62 x 46 mm
📦 INCLUDED:
• Motion detector• Bracket• Instructions
| Model | NVS-OUTDOORPIR |
|---|---|
| Range | Smart Security - Intrusion alarm peripherals |
| Device type | Wireless outdoor motion detector with pet immunity |
| Functions | Motion detection - Reports the presence of people to the alarm panel when the system is armed |
| Technology | Passive Infrared (PIR) volumetric sensor - Detects movement when a body with a temperature similar to the human body crosses the sensor beams - Outdoor temperature compensation (reduces false alarms) - White light filter + Canopy (reduces sunlight interference) - Dual infrared optics with pet immunity - Standby mode (reduces redundant alarms and saves energy) - Tamper alarm |
| Range | Average range 6~9 m - Effective detection angle 110° - Applicable to an estimated area of 12 x 12 m - Pet immunity for animals < 20 kg - Standby mode detection time 5s or 3 min |
| Visual indicator | LED detection indicator - Low battery warning - Walk test indicator |
| Wireless communication with alarm panel | RF Radio 433 MHz - Range up to 150 m in open space |
| Configurable alarm modes linked to the alarm panel | Detection in total arming or perimeter (home) mode |
| Compatibility | Nivian alarm kits with 433 MHz wireless frequencies |
| Installation | Wall mount (bracket included) - Recommended height 2~2.4 m (do not install at < 1.5 m) - Inactivity time setting after the first detection 5s or 3 min via rear switch - Walk test function for checking proper installation |
| Power supply | Battery powered 2 x AA - Standby consumption: ≤8μA - Alarm consumption ≤10mA |
| Material | ABS plastic housing and IR polycarbonate optics |
| Operating temperature | -20°C~50°C |
| Environmental protection | Suitable for indoor and outdoor use |
| Dimensions | 120 x 62 x 46 mm |
- User manual Link
