NDR-75-48
NDR-75-48

Note: actual colors may vary slightly from the images due to different monitor settings and lighting conditions during shooting.

HIKVISION

Hikvision industrial power supply - Output power up to 76.8W

SKU: NDR-75-48
(0)
Out of stock
€44,82 Final price
-2% €45,74 €44,82 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

Hikvision industrial power supply - Output power up to 76.8W - Regulated continuous 48V / 1.6A power supply - Manually adjustable voltage range from 48-55V - Flexible wide-range universal AC/DC input - Ultra-slim format optimized for DIN rail

📋 SPECIFICATIONS:
• Brand: Hikvision
• Component type: Industrial DIN rail power supply
• Mounting format: DIN rail (Compliant with IEC60068-2-6)
• Rated output power: 76.8 W
• Rated output voltage: DC 48 V
• Adjustable voltage range: 48 V to 55 V
• Output current: 1.6 A
• Voltage tolerance: ±1.0%
• Ripple and noise (max.): 150 mVp-p
• AC input range: 100 V AC to 305 V AC (47 Hz to 63 Hz)
• DC input range: 142 V DC to 431 V DC
• AC input current: 1.45 A / 115 VAC | 0.9 A / 230 VAC
• Inrush current: 20 A / 115 VAC | 35 A / 230 VAC
• Energy efficiency: 89%
• Overvoltage protection: 56 V to 65 V (Type: Output shutdown, power cycle to recover)
• Thermal protection: Automatic shutdown for overheating (recovery via power cycle)
• Dielectric isolation (HIPOT): I/P-O/P: 3 KVAC | I/P-FG: 2 KVAC | O/P-FG: 0.5 KVAC
• Operating temperature: -20 °C to 70 °C
• Operating humidity: 20 to 95% RH non-condensing
• Physical dimensions: 32 (Width) x 125.2 (Height) x 102 (Depth) mm
• Net weight: 0.51 kg

📦 INCLUDED:
• 1x Hikvision NDR-75-48 DIN rail power supply
Component type Industrial DIN rail power supply
Mounting format DIN rail (Compliant with IEC60068-2-6)
Rated output power 76.8 W
Rated output voltage 48 V DC
Adjustable voltage range 48 V to 55 V
Output current 1.6 A
Voltage tolerance ±1.0%
Ripple and noise (max.) 150 mVp-p
AC input range 100 V AC to 305 V AC (47 Hz to 63 Hz)
DC input range 142 V DC to 431 V DC
AC input current 1.45 A / 115 VAC | 0.9 A / 230 VAC
Inrush current 20 A / 115 VAC | 35 A / 230 VAC
Energy efficiency 89%
Overvoltage protection 56 V to 65 V (Type: Shut down output, recover after power re-start)
Thermal protection Shut down output voltage (re-power on to recover)
Dielectric insulation (HIPOT) I/P-O/P: 3 KVAC | I/P-FG: 2 KVAC | O/P-FG: 0.5 KVAC
Operating temperature -20 °C to 70 °C
Operating humidity 20 to 95% RH non-condensing
Physical dimensions 32 (Width) x 125.2 (Height) x 102 (Depth) mm
Net weight 0.51 kg
