Hikvision industrial power supply - 240W maximum effective output power
Hikvision industrial power supply - 240W maximum effective output power
Regular price
€114,83
Final price
Regular price
-2%
€117,18
Sale price
€114,83
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Hikvision industrial power supply - 240W effective maximum output power - 48V / 5A regulated continuous power - Wide-range flexible universal AC/DC input - Optimized format for industrial DIN rail
📋 SPECIFICATIONS:
• Brand: Hikvision
• Component type: Industrial DIN rail power supply
• Mounting format: DIN rail (IEC60068-2-6 standard compliance)
• Rated output power: 240 W
• Rated output voltage: 48 V DC
• Adjustable voltage range: 48 V to 55 V
• Output current: 5 A
• Voltage tolerance: ±1.0%
• Ripple and noise (max.): 150 mVp-p
• Line regulation: ±0.5%
• Load regulation: ±1%
• Number of DC outputs: 2
• AC input range: 90 V AC to 264 V AC (47 Hz to 63 Hz)
• DC input range: 127 V DC to 370 V DC
• AC input current: 2.5 A / 115 VAC | 1.3 A / 230 VAC
• Inrush current: 20 A / 115 VAC | 35 A / 230 VAC
• Leakage current: <1 mA / 240 VAC
• Energy efficiency: 90%
• Overvoltage protection: 56 V to 65 V (Type: shut down voltage, power on to recover)
• Thermal protection: Automatic shutdown for overtemperature with electrical autoreset
• Dielectric isolation (HIPOT): I/P-O/P: 3 KVAC | I/P-FG: 2 KVAC | O/P-FG: 0.5 KVAC
• Operating temperature: -20 °C to 70 °C (Subject to derating curve)
• Operating humidity: 20 to 95% RH non-condensing
• Physical dimensions: 63 x 125.2 x 113.5 mm
• Net weight: 1 kg
📦 INCLUDED:
• 1x Hikvision NDR-240-48 DIN rail power supply
| Component type | Industrial DIN rail power supply |
|---|---|
| Mounting format | DIN rail (IEC60068-2-6 compliance) |
| Rated output power | 240 W |
| Rated output voltage | 48 V DC |
| Adjustable voltage range | 48 V to 55 V |
| Output current | 5 A |
| Voltage tolerance | ±1.0% |
| Ripple and noise (max.) | 150 mVp-p |
| Line regulation | ±0.5% |
| Load regulation | ±1% |
| Number of DC outputs | 2 |
| AC input range | 90 V AC to 264 V AC (47 Hz to 63 Hz) |
| DC input range | 127 V DC to 370 V DC |
| AC input current | 2.5 A / 115 VAC | 1.3 A / 230 VAC |
| Inrush current | 20 A / 115 VAC | 35 A / 230 VAC |
| Leakage current | <1 mA / 240 VAC |
| Energy efficiency | 90% |
| Overvoltage protection | 56 V to 65 V (Type: Shut down output voltage, re-power on to recover) |
| Thermal protection | Shut down output voltage, recovers automatically after temperature goes down |
| Dielectric isolation (HIPOT) | I/P-O/P: 3 KVAC | I/P-FG: 2 KVAC | O/P-FG: 0.5 KVAC |
| Operating temperature | -20 °C to 70 °C (Subject to derating curve) |
| Operating humidity | 20 to 95% RH non-condensing |
| Physical dimensions | 63 x 125.2 x 113.5 mm |
| Net weight | 1 kg |
