Wizmart multi-criteria analog detector
Regular price
€38,04
Final price
Regular price
-5%
€40,00
Sale price
€38,04
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Analog multi-criteria detector - Photoelectric smoke detection chamber - Electronic thermistor - Rate-of-rise and fixed temperature - Addressable via DIP switch - High immunity to false alarms
📋 SPECIFICATIONS:
• Type: Addressable photoelectric and thermal detector
• Reference: NB 358D SHL
• Power supply: 17-28 V DC
• Standby consumption: ≤ 800 µA
• Alarm consumption: 5 mA @ 24 V DC
• Smoke detection range: 0.09 dB/m ~ 0.14 dB/m
• Temperature alarm threshold: 59 °C (fixed temperature) or rate-of-rise
• Operating temperature: -10 °C to +50 °C
• Relative humidity: 0% - 95% RH non-condensing
• Dimensions: Ø 100 mm x 48 mm
• Protection rating: IP43
• Communication protocols: Addressable up to 126 addresses per loop
• Indicators: Dual red LED for alarm, 360º visibility
| Type | Addressable photoelectric and thermal detector |
|---|---|
| Reference | NB 358D SHL |
| Power supply | 17-28 V DC |
| Standby current | ≤ 800 µA |
| Alarm current | 5 mA @ 24 V DC |
| Smoke detection range | 0.09 dB/m ~ 0.14 dB/m |
| Temperature alarm threshold | 59 °C (fixed temperature) or rate-of-rise |
| Operating temperature | -10 °C to +50 °C |
| Relative humidity | 0% - 95% RH non-condensing |
| Dimensions | Ø 100 mm x 48 mm |
| Protection rating | IP43 |
| Communication protocols | Addressable up to 126 addresses per loop |
| Indicators | Dual red LED for alarm, 360º visibility |
Same-day shipping if you order before 12:00 PM! In most cases, we rely on couriers with 24-hour service so your order arrives on time.
For orders under €200, the shipping fee is €15.90. For deliveries to remote areas or islands, couriers apply a surcharge to cover transport costs.
The legal warranty lasts 2 years for private individuals (consumers) and 1 year for VAT holders (professionals or companies)
