Milesight temperature monitoring and alert
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
Temperature monitoring and alerting - Hotel system compatibility - Antifreeze protection - LoRaWAN wireless implementation - Up to 1000 logs in the thermostat
📋 SPECIFICATIONS:
• Wireless transmission technology: LoRaWAN®, Milesight D2D
• Frequency: US915/AU915/KR920/AS923-1&2&3&4
• Transmission power: 22 dBm (915 MHz)
• Sensitivity: -137dBm
• Mode: OTAA/ABP Class C
• Compatibility: Works with most 24 VAC HVAC systems, including furnaces and air conditioners (2H/2C), heat pumps (4H/2C + 1 auxiliary heating stage), boilers, and PTACs.
• Control modes: Heating, EM (emergency) Heating, cooling, auto
• Fan modes: Auto, on, circulate
• Digital inputs: 1 × Digital input for 100-250 VAC key card switch
• Advanced functions: Local control programming, threshold alarm, antifreeze protection, child lock, multicast, Milesight D2D controller, Milesight D2D agent, data storage, data retransmission
• Operating principle: CMOSens® digital technology (MEMS)
• Range: -4 °F to 140 °F (-20 °C to 60 °C)
• Accuracy: ± 0.9 °F (32 °F ~ 140 °F), ± 1.8 °F (-4 ~ 32 °F); OR ± 0.5 °C (0 °C ~ 60 °C), ± 1 °C (-20 ~ 0 °C)
• Resolution: 0.1 °F (0.1 °C)
• Operating principle: CMOSens® digital technology (MEMS)
• Range: 0% - 100% RH
• Accuracy: ± 3% RH (40-85% RH), ± 5% RH (0-40% RH, 85-100% RH)
• Resolution: 0.5% RH
• Screen: 4.2-inch segmented LCD display with white backlight
• External buttons: 5 buttons for system power on/off, increase/decrease temperature, temperature control mode switch, fan mode switch, and reset
• Configuration: NFC or USB Type-C
• Installation: Wall screw mounting
• Dimensions: 113 × 110 × 21 mm (4.45 × 4.33 × 0.83 inches)
• Weight: 172g
• Power supply: 20 to 30 VAC, 24 VAC nominal
• Operating temperature: -4 °F to 140 °F (-20 °C to 60 °C)
• Relative humidity: 0% to 95% (non-condensing)
• Protection: IP30
• Material and color: PC + ABS (V0 flame retardant), white
| Wireless transmission technology | LoRaWAN®, Milesight D2D |
|---|---|
| Frequency | US915/AU915/KR920/AS923-1&2&3&4 |
| Transmit power | 22 dBm (915 MHz) |
| Sensitivity | -137dBm |
| Mode | OTAA/ABP Class C |
| Compatibility | Works with most 24 VAC HVAC systems, including furnaces and air conditioners (2H/2C), heat pumps (4H/2C + 1 stage auxiliary heat), boilers, and PTACs. |
| Control modes | Heating, EM (emergency) heating, cooling, auto |
| Fan modes | Auto, on, circulate |
| Digital inputs | 1 × Digital input for 100-250 VAC key card switch |
| Advanced features | Local control scheduling, threshold alarm, anti-freezing protection, child lock, multicast, Milesight D2D controller, Milesight D2D agent, data storage, data retransmission |
| Operating principle | CMOSens® digital technology (MEMS) |
| Range | -4 °F to 140 °F (-20 °C to 60 °C) |
| Accuracy | ± 0.9 °F (32 °F ~ 140 °F), ± 1.8 °F (-4 ~ 32 °F) OR ± 0.5 °C (0 °C ~ 60 °C), ± 1 °C (-20 ~ 0 °C) |
| Resolution | 0.1 °F (0.1 °C) |
| Operating principle | CMOSens® digital technology (MEMS) |
| Range | 0% - 100% RH |
| Accuracy | ± 3% RH (40-85%RH), ± 5% RH (0-40%RH, 85-100%RH) |
| Resolution | 0.5% RH |
| Screen | 4.2-inch segment LCD with white backlight |
| External buttons | 5 buttons for system power on/off, temperature increase/decrease, temperature control mode switch, fan mode switch, and reset |
| Configuration | NFC or USB Type-C |
| Installation | Wall screw mounting |
| Dimensions | 113 × 110 × 21 mm (4.45 × 4.33 × 0.83 inches) |
| Weight | 172g |
| Power supply | 20 to 30 VAC, 24 VAC nominal |
| Operating temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Relative humidity | 0% to 95% (non-condensing) |
| Protection | IP30 |
| Material and color | PC + ABS (V0 flame retardant), white |
