Milesight LoRaWAN control panel
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
LoRaWAN Control Panel - Range up to 15km line-of-sight - User-customizable display - Configuration via NFC and APP - IP30 Protection Rating - Long battery life
📋 SPECIFICATIONS:
• Frequency band: 868 MHz
• Sensitivity: -137dBm@300bps
• Output power: 16dBm Max.
• Protocol: OTAA/ABP Class A
• Communication range: Up to 15 km line-of-sight
• Display: 2.9" E-Ink 128x296
• Other features: User-customizable display
• Interface: 1 external button + 1 LED indicator
• Configuration: NFC via smartphone app
• Buttons: 6
• Power supply: 2x 590 mAh CR2450 batteries
• Battery life: 3 years (20 pulses per day)
• Operating temperature: -10ºC to 50ºC (Relative humidity <90%)
• Protection rating: IP30
• Dimensions: 14 (D) x 86 (H) x 86 (W) mm
• Material: PC+ABS
• Color: White
• Certifications: CE, FCC
📦 INCLUDED:
• Scene panel
• Instruction manual
• Mounting material
| Frequency Band | 868 MHz |
|---|---|
| Sensitivity | -137dBm@300bps |
| Output Power | 16dBm Max. |
| Protocol | OTAA/ABP Class A |
| Communication Range | Up to 15km line-of-sight |
| Display | 2.9" E-Ink 128x296 |
| Other features | User-customizable display |
| Interface | 1 External button + 1 LED indicator |
| Configuration | NFC via smartphone APP |
| Buttons | 6 |
| Power Supply | 2x 590 mAh CR2450 battery |
| Battery Life | 3 years (20 pulses per day) |
| Operating Temperature | -10ºC to 50ºC (Relative humidity <90%) |
| Protection Rating | IP30 |
| Dimensions | 14 (D) x 86 (H) x 86 (W) mm |
| Material | PC+ABS |
| Color | White |
| Certificates | CE, FCC |
