Milesight LoRaWAN Smart Button
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
LoRaWAN Smart Button - Up to 15km range with line-of-sight - Multiple trigger modes - Configuration via NFC and APP - IP30 Protection Rating - Long battery life
📋 SPECIFICATIONS:
• Frequency band: 868 MHz
• Sensitivity: -137dBm@300bps
• Output power: 16dBm Max.
• Protocol: OTAA/ABP Class A
• Communication range: Up to 15 km line-of-sight
• Interface: 1 external button + 1 internal button (Reset) + Buzzer
• Configuration: NFC via smartphone app
• Reliability: WAN failover
• Power supply: 1x 1650 mAh ER14335 Li-SOCl2 battery
• Battery life: 5 years (10 triggers per day)
• Operating temperature: -20ºC to 60ºC (Relative humidity <90%)
• Protection rating: IP30
• Dimensions: 18 (D) x 50 (H) x 50 (W) mm
• Material: Fire-retardant polycarbonate
• Color: White
• Certifications: CE, FCC
📦 INCLUDED:
• Scene panel• Instruction manual• Mounting hardware
| Frequency Band | 868 MHz |
|---|---|
| Sensitivity | -137dBm@300bps |
| Output Power | 16dBm Max. |
| Protocol | OTAA/ABP Class A |
| Communication Range | Up to 15km line-of-sight |
| Interface | 1 external button + 1 internal button (Reset) + Buzzer |
| Configuration | NFC via smartphone APP |
| Reliability | WAN Failover |
| Power Supply | 1x 1650 mAh ER14335 Li-SOCI2 battery |
| Battery Life | 5 years (10 pulses per day) |
| Operating Temperature | -20ºC to 60ºC (Relative humidity <90%) |
| Protection Rating | IP30 |
| Dimensions | 18 (D) x 50 (H) x 50 (W) mm |
| Material | Flame-retardant polycarbonate |
| Color | White |
| Certificates | CE, FCC |
