Milesight LoRaWAN presence sensor - Detection area up to 78㎡
Regular price
€386,00
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
LoRaWAN Presence Sensor - Detection area up to 78㎡ - 100% anonymous detection - Numerous advanced functions - 16 detection areas - Range up to 15km with line-of-sight
📋 SPECIFICATIONS:
• Technology: LoRaWAN®
• Frequency Band: 868 MHz
• Output Power: 16dBm Max.
• Sensitivity: -137 dBm @300bps
• Mode: OTAA/ABP Class C
• Communication Range: Up to 15km with line-of-sight
• Field of View: 190° Horizontal, 112° Vertical
• Detection Area: 5m radius at a height of 3m (78㎡)
• Light Sensor: Bright/Dark (configuration between 1-60000 lux as Bright or Dark based on custom threshold)
• Configuration: NFC via smartphone APP
• Power Supply: 1x 1650 mAh ER14335 Li-SOCI2 battery
• Battery Life: 4 years (30 detections per day)
• Operating Temperature: -20ºC to 60ºC (Relative humidity < 90%)
• Protection Rating: IP30
• Dimensions: 23.8 (D) x 50 (W) x 50 (H) mm
• Material: Flame retardant polycarbonate
• Color: White
• Certificates: CE, FCC, RoHS
• Installation Height: 2.5~4m
• Recognition Rate: Area counting: up to 95%; Line crossing counting: up to 98%
📦 INCLUDED:
• Occupancy sensor• Instruction manual• Mounting material
| Technology | LoRaWAN® |
|---|---|
| Frequency Band | 868 MHz |
| Output Power | 16dBm Max. |
| Sensitivity | -137 dBm @300bps |
| Mode | OTAA/ABP Class C |
| Communication Range | Up to 15km line-of-sight |
| Field of View | 190° Horizontal, 112° Vertical |
| Detection Area | 5m radius at 3m height (78㎡) |
| Light Sensor | Bright/Dark (configurable between 1-60000 lux as Bright or Dark based on custom threshold) |
| Configuration | NFC via smartphone APP |
| Power Supply | 1x 1650 mAh ER14335 Li-SOCI2 battery |
| Battery Life | 4 years (30 detections per day) |
| Operating Temperature | -20ºC to 60ºC (Relative humidity < 90%) |
| Ingress Protection | IP30 |
| Dimensions | 23.8 (D) x 50 (W) x 50 (H) mm |
| Material | Flame-retardant polycarbonate |
| Color | White |
| Certificates | CE, FCC, RoHS |
| Installation Height | 2.5~4m |
| Recognition Rate | Area counting: up to 95% Line crossing counting: up to 98% |
