Note: actual colors may vary slightly from the images due to different monitor settings and lighting conditions during shooting.

MILESIGHT

Milesight LoRaWAN IoT Controller with up to 15km range and direct visualization

SKU: MS-UC100-868M
(0)
In stock
Usually shipped within 24 hours
€87,62 Final price
-9% €96,00 €87,62 Final price
Ready to use

Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.

Free shipping on orders over €200
100% Secure Payments
Industry-leading quality

Do you have any questions?

Feel free to write to us

Ask an expert!

WhatsApp Telegram Email

Ti rispondiamo entro 24 ore. Per una risposta subito, l'assistente in basso a destra.

LoRaWAN IoT Controller - Range up to 15km line-of-sight - Configuration via NFC and APP - Up to 16 Modbus RTU devices - Indoor installation

📋 SPECIFICATIONS:
• Technology: LoRaWAN®
• Frequency band: 868 MHz
• Output power: 16dBm Max.
• Sensitivity: -137 dBm @300bps
• Mode: OTAA/ABP Class C
• Interface type: 1x RS485; 3.5 mm Terminal block
• Terminal resistance: 1 x 120 Ω Resistor switch
• Baud rate: 1200~115200 bps: Transparent (RS232), Modbus RTU (RS485)
• Protocol: Modbus RTU (RS485), Passthrough
• Power supply: 5-24 VDC; 5 VDC Type-C
• Operating temperature: -20ºC ~ 60ºC
• Environmental protection: IP30
• Dimensions: 70 x 45 x 13 mm

📦 INCLUDED:
• IoT Controller• Connector• Installation accessories• User manual
Technology LoRaWAN®
Frequency Band 868 MHz
Output Power 16dBm Max.
Sensitivity -137 dBm @300bps
Mode OTAA/ABP Class C
Interface Type 1x RS485 3.5 mm Terminal Block
Terminal Resistance 1 x 120 Ω Resistor Switch
Baud rate 1200~115200 bps: Transparent (RS232), Modbus RTU (RS485)
Protocol Modbus RTU (RS485), Passthrough
Power Supply 5-24 VDC 5 VDC Type-C
Operating Temperature -20ºC ~ 60ºC
Environmental Protection IP30
Dimensions 70 x 45 x 13 mm
