Milesight OpenVision mini server - Network Optix VMS pre-installed, licenses not included
Milesight OpenVision mini server - Network Optix VMS pre-installed, licenses not included
Regular price
€1.187,49
Final price
Regular price
-6%
€1.268,00
Sale price
€1.187,49
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Milesight OpenVision mini server - Network Optix VMS preinstalled, licenses not included - NX client included (for use with monitor/keyboard/mouse) - Max. 4K resolution | 8 channels - Mounting brackets included - 2x HDMI | 2 M.2 slots max. 4TB per device
📋 SPECIFICATIONS:
• Brand: Milesight
• Range: OpenVision
• Hardware: Main processor: Intel N150 Quad Core @3.40 GHz; Memory: 4GB LPDDR5; Local network: 2 x 2500Mbps RJ45, supports PoE PD, Link Aggregation, LAN1 supports PoE PD; OS: Linux Ubuntu 24.04 LTS; Integrated GPU; TPM: fTPM
• Software: Network Optix VMS preinstalled (NX licenses not included)
• IP camera inputs: LAN port up to 8 channels
• Resolution: 12Mpx~CIF
• Compatible IP cameras: ONVIF Profile S/T/G/M
• Two-way audio: Supported (microphone/speaker jack connector)
• Video output: 2 x HDMI
• Total bandwidth: 80Mbps input / 160Mbps output
• Multifunction: Pentaplex: live, recording, playback, backup and remote access
• Recording modes: Continuous, event (object, motion detection, alarm, VCA, intelligent analysis)
• Event analysis recording (supported by the camera): CCTV (intrusion / area entry / area exit / advanced motion detection / line crossing / loitering / abandoned object / removed object / target counting / people counting in area);; LPR (event by characteristics / blacklist / whitelist / visit list / speed control / missing license plate / wrong-way driving);; Object detection events (people and vehicles with characteristics / faces)
• Intelligent search (supported by the camera): CCTV: Person (helmet, upper clothing color, lower clothing color),; Vehicle (vehicle type), face (gender, age, mask, hat, glasses);; LPR: vehicle (color, vehicle type, brand, speed, direction of travel),; license plate (number, color, country, plate type)
• Event actions: Marker, camera output, camera recording, HTTP(S) commands, access PTZ presets, play audio, etc..
• Internal storage: 2 x M.2 NVMe SSD up to 4TB per drive (not included)
• External interface: 2 x RJ45 10/100/1000/2500Mbps, 3 x USB 3.0, 1 x USB 2.0
• Ethernet Link Aggregation: Active Backup, Link Aggregation Control Protocol (LACP) and Adaptive Load Balancing (ALB)
• Audio: Two-way; 1 headset connector with microphone input
• Inputs / Outputs: 4 inputs and 2 relay outputs
• Remote access: Web browser, smartphone app and Network Optix VMS
• Operating conditions: Temperature: -20℃~60℃; Humidity: 10%~90% (without freezing or condensation)
• Power supply: PoE+ (802.3at) / DC 12V±15% (5525 DC power connector)
• Power consumption: Typical: 6W (without SSD, DC), 8W (without SSD, PoE); Max.: 16W (with SSD, DC), 18W (with SSD, PoE)
• Dimensions: 135mm (W) x 140mm (D) x 40mm (H)
• Installation: VESA mount; DIN rail mount; Support brackets
• Weight: 1.3 Kg
• Compliance: NDAA
📦 INCLUDED:
• Milesight OpenVision mini NVR server• DIN rail mounting brackets and arms included• Video cable• Documentation
| Range | OpenVision |
|---|---|
| Hardware | Main Processor: Intel N150 Quad Core @3.40 GHz Memory: 4GB LPDDR5 Local Network: 2 x 2500Mbps RJ45, supports PoE PD, Link Aggregation, LAN1 supports PoE PD OS: Linux Ubuntu 24.04 LTS Integrated GPU TPM: fTPM |
| Software | Network Optix VMS preinstalled (NX licenses not included) |
| IP camera inputs | LAN port up to 8 channels |
| Resolution | 12Mpx~CIF |
| Compatible IP cameras | ONVIF Profile S/T/G/M |
| Two-way audio | Supported (microphone/speaker jack connector) |
| Video output | 2 x HDMI |
| Total bandwidth | 80Mbps input / 160Mbps output |
| Multifunction | Pentaplex: live, recording, playback, backup and remote access |
| Recording modes | Continuous, event (object, motion detection, alarm, VCA, intelligent analysis) |
| Event analysis recording (camera supported) | CCTV (intrusion / area entry / area exit / advanced motion detection / line crossing / loitering / abandoned object / taken object / target counting / people counting in area); LPR (event by characteristics / blacklist / whitelist / visit list / speed control / missing license plate / wrong-way driving); Object detection events (people and vehicles with characteristics / faces) |
| Smart search (camera supported) | CCTV: Person (helmet, upper clothing color, lower clothing color), Vehicle (vehicle type), face (gender, age, mask, hat, glasses); LPR: vehicle (color, vehicle type, brand, speed, direction of travel), license plate (number, color, country, plate type) |
| Actions by event | Marker, camera output, camera recording, HTTP(S) commands, access PTZ presets, play audio, etc. |
| Internal memory | 2 x M.2 NVMe SSD up to 4TB per drive (not included) |
| External interface | 2 x RJ45 10/100/1000/2500Mbps, 3 x USB 3.0, 1 x USB 2.0 |
| Ethernet Link Aggregation | Active Backup, Link Aggregation Control Protocol (LACP) and Adaptive Load Balancing (ALB) |
| Audio | Two-way 1 headphone connector with microphone input |
| Inputs / Outputs | 4 inputs and 2 relay outputs |
| Remote access | Web browser, smartphone app and Network Optix VMS |
| Operating conditions | Temperature: -20℃~60℃ Humidity: 10%~90% (without freezing or condensation) |
| Power supply | PoE+ (802.3at) / DC 12V±15% (5525 DC power connector) |
| Consumption | Typical: 6W (without SSD, DC), 8W (without SSD, PoE) Max.: 16W (with SSD, DC), 18W (with SSD, PoE) |
| Dimensions | 135mm (W) x 140mm (D) x 40mm (H) |
| Installation | VESA mount DIN rail mount Support arms |
| Weight | 1.3 kg |
| Compliance | NDAA |
