1/3" Sony© Super HAD CCD II wired minicamera
1/3" Sony© Super HAD CCD II wired minicamera
Regular price
€43,81
Final price
Regular price
-9%
€48,00
Sale price
€43,81
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Wired minicamera - 1/3" Sony© Super HAD CCD II - 600 TVL resolution - Built-in bracket - 0.3 Lux / F2.0 - 3.7 mm Pinhole lens
📋 SPECIFICATIONS:
• Optical sensor: 1/3" Sony© 960H Super HAD CCD II
• DSP: Nextchip NVP2040
• Resolution: 600 TVL
• Video output: 1 Vp-p 75 Ω / BNC
• Minimum illumination: 0.3 Lux / F2.0
• S/N ratio: > 48 dB
• Lens: 3.7 mm (79º) Pinhole
• Power supply: DC 12 V / 150 mA
• Operating temp.: -10º C ~ +50º C
• Dimensions: 25 (W) x 25 (H) x 14 (D) mm
• Weight: 24 g
📦 INCLUDED:
• Mini camera• Video and power cable connection• User manual
| Optical sensor | 1/3" Sony© 960H Super HAD CCD II |
|---|---|
| DSP | Nextchip NVP2040 |
| Resolution | 600 lines |
| Video output | 1 Vp-p 75 Ω / BNC |
| Minimum illumination | 0.3 Lux / F2.0 |
| S/N ratio | > 48 dB |
| Lens | 3.7 mm (79º) Pinhole |
| Power supply | DC 12 V / 150 mA |
| Operating temp. | -10º C ~ +50º C |
| Dimensions | 25 (W) x 25 (H) x 14 (D) mm |
| Weight | 24 g |
- User manual Link
