EoC Branded Ethernet Extender over coaxial cable - Passive PoE
EoC Branded Ethernet Extender over coaxial cable - Passive PoE
Regular price
€41,50
Final price
Regular price
-10%
€46,00
Sale price
€41,50
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Branded EoC Extender - Ethernet over Coaxial - Passive PoE - Receiver compatible with LR1002 range - Allows transmission of 1 IP channel - Maximum distance 1000 m
📋 SPECIFICATIONS:
• Coaxial connection: Female BNC connector and RJ45 connector
• Transmission speed: 100 Mbps symmetrical (100 Mbps upstream 100 Mbps downstream)
• Distance over coaxial: 100 m between extenders up to 100Mbps (Up to 21W power with 48V DC and 25.5W powered with 53V DC); 400 m between extenders up to 100Mbps (Up to 9W power with 48V DC and 16W powered with 53V DC); 800 m between extenders up to 10Mbps (Up to 5W power with 48V DC and 8W powered with 53V DC); 1000 m between extenders up to 10Mbps (Up to 4W power with 48V DC and 6W powered with 53V DC)
• Connection: Converter for PoE cameras / receiver
• PoE protocol: Passive PoE
• Weight: 61 g
📦 INCLUDED:
• EoC extender
| Coaxial connection | Female BNC connector and RJ45 connector |
|---|---|
| Transmission speed | 100 Mbps symmetrical (100 Mbps upstream, 100 Mbps downstream) |
| Distance over coaxial | 100 m between extenders up to 100Mbps (Up to 21W power with 48V DC and 25.5W powered with 53V DC) 400 m between extenders up to 100Mbps (Up to 9W power with 48V DC and 16W powered with 53V DC) 800 m between extenders up to 10Mbps (Up to 5W power with 48V DC and 8W powered with 53V DC) 1000 m between extenders up to 10Mbps (Up to 4W power with 48V DC and 6W powered with 53V DC) |
| Connection | Converter for PoE cameras / receiver |
| PoE protocol | Passive PoE |
| Weight | 61 g |
Same-day shipping if you order before 12:00 PM! In most cases, we rely on couriers with 24-hour service so your order arrives on time.
For orders under €200, the shipping fee is €15.90. For deliveries to remote areas or islands, couriers apply a surcharge to cover transport costs.
The legal warranty lasts 2 years for private individuals (consumers) and 1 year for VAT holders (professionals or companies)
