Jade Bird infrared linear smoke detector

Linear infrared smoke detector - Motorized head with self-alignment - Simple configuration via mobile app - Dirt compensation - Range up to 70m - Expandable up to 160m with the use of a kit

📋 SPECIFICATIONS:
• Power supply: 12 to 30 VDC
• Consumption (operational): 5.5 mA
• Consumption (start-up): 17 mA
• Range: From 7 to 160 meters (depending on accessories)
• Operating temperature: -10ºC to 55ºC
• Relative humidity: From 10% to 95% (non-condensing)
• Protection rating: IP65
• Relay outputs: Alarm (NO/NC) and Fault (NO/NC) - 2A @ 30Vdc
• Certification: EN 54-12:2015
• Dimensions (transmitter): 180 mm x 155 mm x 137 mm
• Weight (transmitter): 1.1 kg

📦 INCLUDED:
• Motorized infrared Emitter/Receiver head
• Control unit for system processing and management
• Reflector (100x100 mm) prism for signal return (up to 70m)
