PoE Injector and Splitter
Couldn't load pickup availability
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Do you have any questions?
Ask an expert!
PoE Injector and Splitter. - Requires use of the included pair. - Input and output voltage up to 48 V. - RJ45 connectors and power jack. - Transmission distance up to 100 meters UTP. - Compact and lightweight model, black color.
📋 SPECIFICATIONS:
• Device type: Passive PoE injector and splitter kit (combined pair)
• Data / network interface: 10/100 Mbps RJ45 female input / output
• Power interface: Power jack input / output (2.1 mm x 5.5 mm)
• Power supply: Up to DC 48V (power adapter not included)
• PoE features: Passive PoE (proprietary) / Pin 4-5 power / Pin 7-8 GND
• Maximum transmission range: Up to 100 meters with UTP cable
• Installation mode: Indoor installation / flexible next to the switch and the camera
• Chassis color: Black
• Cable length: 175 mm
• Connector size: 2.1 x 5.5 mm
📦 INCLUDED:
• 1x PoE injector• 1x PoE splitter
| Device type | Passive PoE injector and splitter kit (combined pair) |
|---|---|
| Data / network interface | 10/100 Mbps RJ45 female input / output |
| Power interface | Power jack input / output (2.1 mm x 5.5 mm) |
| Power supply | Up to DC 48V (power adapter not included) |
| PoE features | Passive PoE (proprietary) / Pin 4-5 power / Pin 7-8 GND |
| Maximum transmission range | Up to 100 meters with UTP cable |
| Installation mode | Indoor installation / flexible next to switch and camera |
| Case color | Black |
| Cable length | 175 mm |
| Connector dimensions | 2.1 x 5.5 mm |
- User manual Link
