High-performance dual-port PoE injector
Regular price
€48,42
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
High-performance dual-port PoE injector. - Supports IEEE 802.3af/at standards. - Features 3 RJ45 ports (2 PoE + 1 uplink). - Total power output up to 60W. - 10/100/1000M Gigabit data transfer. - DIP switch for extension up to 250m.
📋 SPECIFICATIONS:
• Device type: Dual Gigabit PoE injector
• Network interface: 2x 10/100/1000M PoE ports + 1x 10/100/1000M uplink port
• Transfer speed: 10 / 100 / 1000 Mbps (Gigabit Ethernet)
• Supported PoE standards: IEEE 802.3af / IEEE 802.3at (up to 30W per port)
• Maximum output power: 60W total (Max. 30W each)
• Power supply voltage: 52 V / 1.25 A
• Forwarding mode: Store and forward
• Switching capacity: 12 Gbps (non-blocking)
• Extension function: DIP extended mode up to 250 meters (at 10 Mbps)
• PoE pin assignment: 1/2 (+), 3/6 (-)
• MAC address table: 2K
• Buffer memory: 2 M
• LED indicators: Power (PWR), Data (Link), PoE status
• Network standards: IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Operating temperature: -20°C to ~ 55°C
• Operating humidity: 5% to 90% RH (non-condensing)
• Physical dimensions: 29 x 50 x 103 mm
📦 INCLUDED:
• 1x Dual PoE Injector INJ-POE-G-60W-DUAL
• 1x External power supply 52 V / 1.25 A
• 1x Manual and instructions
| Device type | Dual Gigabit PoE Injector |
|---|---|
| Network interface | 2x 10/100/1000M PoE ports + 1x 10/100/1000M uplink port |
| Transfer rate | 10 / 100 / 1000 Mbps (Gigabit Ethernet) |
| Supported PoE standards | IEEE 802.3af / IEEE 802.3at (up to 30W per port) |
| Maximum power output | 60 W total (Max. 30W each) |
| Power supply voltage | 52 V / 1.25 A |
| Forwarding mode | Store and Forward |
| Switching capacity | 12 Gbps (non-blocking) |
| Extension function | DIP extended mode up to 250 meters (at 10 Mbps) |
| PoE pin assignment | 1/2 (+), 3/6 (-) |
| MAC address table | 2K |
| Buffer memory | 2 M |
| LED indicators | Power (PWR), Data (Link), PoE Status |
| Network standards | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Operating temperature | -20°C to ~ 55°C |
| Operating humidity | 5% to 90% RH (non-condensing) |
| Physical dimensions | 29 x 50 x 103 mm |
- User manual Link
