High-efficiency passive PoE injector - Stable power supply up to 12 W
High-efficiency passive PoE injector - Stable power supply up to 12 W
Regular price
€11,99
Final price
Regular price
-3%
€12,40
Sale price
€11,99
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
High-efficiency passive PoE injector. - Compatibility with passive PoE technology. - Features 2 RJ45 ports (input/output). - Stable power supply up to 12 W. - 10/100/1000M Gigabit data transfer. - Optimized for Reyee radio links and more.
📋 SPECIFICATIONS:
• Device type: Gigabit passive PoE injector
• Network interface: 10/100/1000 Mbps RJ45 Input / Output
• Transfer speed: 10 / 100 / 1000 Mbps (Gigabit Ethernet)
• PoE features: Passive PoE (pins 4-5 positive, pins 7-8 negative)
• Maximum output power: 12 W
• Output voltage: 24 Vdc
• Output current: 0.5 A
• AC input voltage: 100 - 240 Vac (50/60 Hz)
• Power connector: 2-pin C8 type
• Optimized use cases: Powering Reyee radio links and compatible brands
• Maximum transmission range: 100 meters
• Installation mode: Indoor / desktop installation
• Operating temperature: -10°C to ~ 40°C
• Operating humidity: 35% to 90% RH (non-condensing)
• Physical dimensions: 110 x 45 x 33 mm
📦 INCLUDED:
• 1x INJ-POE-24W passive PoE injector
• 1x Quick installation guide
| Device type | Passive Gigabit PoE injector |
|---|---|
| Network interface | 10/100/1000 Mbps RJ45 Input / Output |
| Transfer speed | 10 / 100 / 1000 Mbps (Gigabit Ethernet) |
| PoE features | Passive PoE (pins 4-5 positive, pins 7-8 negative) |
| Maximum output power | 12 W |
| Output voltage | 24 Vdc |
| Output current | 0.5 A |
| AC input voltage | 100 - 240 Vac (50/60 Hz) |
| Power connector | 2-pin C8 type |
| Optimized use cases | Powering Reyee radio links and compatible brands |
| Maximum transmission range | 100 meters |
| Installation mode | Indoor / Desktop installation |
| Operating temperature | -10°C to ~ 40°C |
| Operating humidity | 35% to 90% RH (non-condensing) |
| Physical dimensions | 110 x 45 x 33 mm |
- User manual Link
