DSPPA 100V Mini Digital Mixer Amplifier - 120W Rated Power
DSPPA 100V Mini Digital Mixer Amplifier - 120W Rated Power
Regular price
€228,27
Final price
Regular price
-5%
€240,00
Sale price
€228,27
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Mini digital mixer - 100V amplifier - USB player / FM radio / Bluetooth - 120W rated power - Line output - Remote control included
📋 SPECIFICATIONS:
• Model: MP120UB
• Power consumption: 10W
• Power supply: 110 - 240V AC @ 50/60Hz
• Inputs: 2 x MIC (1 x 6.3 mm Jack, 1 x XLR phantom); 2 x LINE; 2 x Emergency signal (EMC)
• Priority function: EMC / MIC1 > AUX1 / AUX2 / MIC2
• Input signal sensitivity: MIC 1 and MIC 2: 7mV±1mV; AUX 1 and AUX 2: 300mV±10%; EMC: 350mV±10%
• Frequency response: MIC: 100Hz~8kHz (±3dB); AUX: 80Hz~15kHz (±3dB)
• Volume control: Master; Individual for MIC and LINE; Treble and bass
• Outputs: 1 x LINE; 1 x Emergency signal output (EMC)
• Bluetooth: Yes
• FM radio: Yes
• USB player: Yes
• Output noise level: ≤6mV (4Ω)
• Total harmonic distortion (THD): <1% 1 kHz
• Treble adjustment: 10dB (±2)
• Bass adjustment: 10dB (±2)
• Rated output power: 120W
• Output interface: 70V, 100V (constant voltage output); 4-16Ω
• Dimensions: 198 × 247 x 66 mm (D x W x H); 1.5U
• Weight: 3kg
📦 INCLUDED:
• Amplifier-mixer
| Model | MP120UB |
|---|---|
| Power consumption | 10W |
| Power supply | 110 - 240V AC @ 50/60Hz |
| Inputs | 2 x MIC (1 x 6.3mm Jack, 1 x XLR phantom), 2 x LINE, 2 x Emergency signal (EMC) |
| Priority function | EMC / MIC1 > AUX1 / AUX2 / MIC2 |
| Input signal sensitivity | - MIC 1 and MIC 2: 7mV±1mV - AUX 1 and AUX 2: 300mV±10% - EMC: 350mV±10% |
| Frequency response | - MIC: 100Hz~8kHz (±3dB) - AUX: 80Hz~15kHz (±3dB) |
| Volume control | - Master - Individual for MIC and LINE - Treble and bass |
| Outputs | 1 x LINE, 1 x Emergency signal output (EMC) |
| Bluetooth | Yes |
| FM Radio | Yes |
| USB Player | Yes |
| Output noise level | ≤6mV (4Ω) |
| Total harmonic distortion (THD) | <1% 1KHZ |
| Treble adjustment | 10dB (±2) |
| Bass adjustment | 10dB (±2) |
| Rated output power | 120W |
| Output interface | 70V, 100V (constant voltage output), 4-16Ω |
| Dimensions | 198 × 247 x 66 mm (D x W x H) 1.5U |
| Weight | 3kg |
- User manual Link
