DSPPA Ceiling Speaker - 1x5" + 1x1" Full-range Speaker - 70V / 100V Power
DSPPA Ceiling Speaker - 1x5" + 1x1" Full-range Speaker - 70V / 100V Power
Regular price
€64,56
Final price
Regular price
-8%
€70,00
Sale price
€64,56
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Ceiling speaker - 1x5" + 1x1" full-range speaker - 70V / 100V power - 90dB sensitivity - 80Hz - 20kHz range
📋 SPECIFICATIONS:
• Model: DSP8063
• Speaker type: Wall-mount speaker
• Connection: Push-wire connection (jumper terminal - 2-tap type)
• Rated input (high impedance): 70V line: 2.5W / 5W / 15W / 30W; 100V line: 5W / 8W / 15W / 30W
• Impedance: 8Ω
• Speaker component: 1 x 5"; 1 x 1"
• Sensitivity (1W, 1m): 90dB ± 2dB
• Frequency response: 80Hz - 20kHz
• SPL (max): 105dB±2dB (1m)
• Grille: 1060 pure aluminum with hardening and anti-oxidation treatment
• Material: Housing: UL94V-0 grade fireproof ABS; Treble diaphragm: natural silk; Bass diaphragm: polypropylene
• Bracket: Anti-corrosion treatment
• Dimensions: 194mm (W) x 280mm (H) x 185mm (D)
• Weight: 3.2Kg
📦 INCLUDED:
• Wall-mount speaker • Bracket
| Model | DSP8063 |
|---|---|
| Speaker type | Wall-mounted speaker |
| Connection | Push-wire connection (jumper terminal - 2-tap type) |
| Rated input (high impedance) | - 70V line: 2.5W / 5W / 15W / 30W - 100V line: 5W / 8W / 15W / 30W |
| Impedance | 8Ω |
| Speaker component | 1 x 5" 1 x 1" |
| Sensitivity (1W, 1m) | 90dB ± 2dB |
| Frequency response | 80Hz - 20kHz |
| SPL (max) | 105dB±2dB (1m) |
| Grille | 1060 pure aluminum with hardening and anti-oxidation treatment |
| Material | - Housing: UL94V-0 grade fireproof ABS - Treble diaphragm: natural silk - Bass diaphragm: polypropylene |
| Bracket | Anti-corrosion treatment |
| Dimensions | 194mm (W) x 280mm (H) x 185mm (D) |
| Weight | 3.2kg |
