DSPPA Desktop Paging Microphone - DMA20
DSPPA Desktop Paging Microphone - DMA20
Regular price
€281,31
Final price
Regular price
-7%
€302,00
Sale price
€281,31
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Desktop microphone - Announcement button - Up to 6 microphones can be cascaded - Powered by amplifier - Compatible with DSPPA-DMA6250U - Compatible with DSPPA-DMA6500U
📋 SPECIFICATIONS:
• Model: DMA20
• Sensitivity: 30 ± 3mV
• Frequency response: 200Hz - 15KHz
• Signal-to-noise ratio (SNR): ≥ 70db
• Compatibility: With mixer-amplifiers: DSPPA-DMA6250U; DMA6350U; DSPPA-DMA6500U; DMA6650U
• RJ45 port: 2 x RJ45 (Communication via RS485 protocol with mixer amplifier)
• Connection with DMA series mixer amplifiers: CAT5e cable (or higher) with resistance ≤12Ω per 100 meters; Up to 6 microphones can be cascaded; With one microphone connected to the amplifier, the maximum distance between the amplifier and the microphone is 600m; When more than one microphone is connected in cascade, the distance between the first microphone and the amplifier and between the microphones is 300m
• Connections: 1 x XLR connector (5-pin)
• Power supply: Provided by the mixer amplifier or the microphone preamplifier (when connecting several in cascade)
• Indicator lights: On the microphone neck to indicate activation; On the microphone base to indicate volume (4 LEDs); On the microphone base to indicate if the microphone is powered; On the microphone base to indicate AUX / MP3 signal usage
• Volume control: For AUX / MP3 signals
• Zone selection: 6 buttons on the microphone base for selecting each zone; 1 button on the microphone base for selecting all zones
• Source selection: 1 button on the microphone base for selecting AUX / MP3
• Microphone activation: 1 button on the microphone base to activate / deactivate voice transmission
• Warning signal activation: 1 button on the microphone base
• Gain control: 1 potentiometer on the back of the microphone base
• Dimensions: 172 × 160 × 53 mm (H x W x D)
• Weight: 0.89 Kg
📦 INCLUDED:
• Microphone
| Model | DMA20 |
|---|---|
| Sensitivity | 30 ± 3mV |
| Frequency response | 200Hz -15KHz |
| Signal-to-noise ratio (SNR) | ≥ 70dB |
| Compatibility | With mixer amplifiers: DSPPA-DMA6250U, DMA6350U, DSPPA-DMA6500U, DMA6650U |
| RJ45 port | 2 x RJ45 (Communication via RS485 protocol with mixer amplifier) |
| Connection to DMA series mixer amplifiers | - CAT5e (or higher) cable with resistance ≤12Ω per 100 meters - Up to 6 microphones can be daisy-chained - With one microphone connected to the amplifier, the maximum distance between the amplifier and the microphone is 600m - When more than one microphone is daisy-chained, the distance between the first microphone and the amplifier and between the microphones is 300m |
| Connections | 1 x XLR connector (5-pin) |
| Power supply | Provided by the mixer amplifier or microphone preamplifier (when connecting several in a daisy chain) |
| Indicator lights | - On the microphone neck to indicate activation - On the microphone base to indicate volume (4 LEDs) - On the microphone base to indicate power status - On the microphone base to indicate AUX / MP3 signal usage |
| Volume control | For AUX / MP3 signals |
| Zone selection | - 6 buttons on the microphone base for selecting each zone - 1 button on the microphone base for selecting all zones |
| Source selection | 1 button on the microphone base for selecting AUX / MP3 |
| Microphone activation | 1 button on the microphone base to activate / deactivate voice transmission |
| Chime activation | 1 button on the microphone base |
| Gain control | 1 potentiometer on the back of the microphone base |
| Dimensions | 172 × 160 × 53 mm (H x W x D) |
| Weight | 0.89 kg |
- User manual Link
