Hikvision network amplifier with basic mixing functions - 1000 W rated power
Hikvision network amplifier with basic mixing functions - 1000 W rated power
Regular price
€1.127,93
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
Network amplifier - Basic mixing functions - 100 V amplifier - USB / BT / MIC / RCA player - Rated power 1000 W - Up to 4 zones
📋 SPECIFICATIONS:
• Network protocol: IPv4, HTTP, HTTPS, SIP, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, NTP, RTP
• Interface protocol: ISAPI, ISUP, SIP, RTP (API)
• Audio bit rate: G.711ulaw (64 Kbps); G.711alaw (64 Kbps); MP3 (128 Kbps); AAC (128 Kbps）
• Protection functions: Short circuit; Overcurrent; Overheating; Static electricity; Surge; Electric discharge
• Rated power: 1,000 W
• Frequency response: 100 V COM / 70 V COM: 50 ~ 20,000 Hz (±3 dB); RCA Out / 3.5 mm out: 50 ~ 20,000 Hz (±1 dB)
• Total Harmonic Distortion (THD): <0.5 % at 1 kHz, 1/3 rated power
• Signal-to-Noise Ratio (SNR): > 90 dB
• Alarm (Euroblock): 1x EVAC alarm; 1x Alarm input; 1x Alarm output; If the device connected to the alarm output is "normally closed", connect: 1A to GND; if it is "normally open", connect: 1B to GND.
• Ethernet (RJ45): 1x LAN (10 / 100 / 1000 M)
• Local storage: 4 GB (EMMC); The available space for audio files is 1 GB.
• Audio: INPUTS:; 4x MIC (6.35 mm Jack) -28 dBV, 4.7 kΩ, unbalanced output (cannot be connected without a microphone); 4x RCA (Pin Jack) 0 dBV, 4.7 kΩ, unbalanced output; 1x USB 2.0; Bluetooth 5.0 (10 m pick-up range); OUTPUTS:; 4x Constant voltage output 100 V COM and 70 V COM; A single channel supports an output power of up to 250 W; 2x RCA (Pin Jack) 0 dBV, unbalanced output; 2x Output (3.5 mm Jack) 0 dBV, unbalanced output; If constant voltage mode is set to 100 V, the output interface must be connected to a loudspeaker with a rated voltage of 100 V. Connecting to a 70 V rated loudspeaker may damage the device.
• LED indicator: 1x Power: Solid white light, the device is working correctly.; 1x USB: Solid white light, the device is in USB mode.; 1x Bluetooth: Solid blue light, the device is in Bluetooth mode.; 1x EVAC: Solid red light, the EVAC alarm has been activated.; 1x MIC 1: Solid white, the MIC 1 input is connected correctly.; 1x Module: Solid FLT, indicates an overload or other system faults.; 1x CLIP: Solid light, indicates clipping or other anomalies.; 1x SIG: solid light, indicates normal operation.
• Volume: 1x Master (potentiometer); 4x MIC input (potentiometer); 4x RCA input (potentiometer); 4x Output channel (potentiometer); 1x Treble (potentiometer); 1x Bass (potentiometer)
• USB: 1x USB 2.0; Compatible formats: FAT32 (maximum partition capacity: 32 GB) and EXFAT (maximum partition capacity: 256 GB)
• Power supply: 100 ~ 240 V AC
• Power consumption: 80 W (standby mode); 200 W (max.)
• Material: Front panel: PC + ABS; Top and bottom panel: SGCC
• Dimensions: 495.97 (W) × 90.89 (H) × 473.18 (D) mm
• Weight: 6.6 Kg
• Color: Black
• Working conditions: Temperature: -10 ~ 50 °C; Humidity: ＜90 % (no condensation)
📦 INCLUDED:
• Network amplifier• Power cable
| Network protocols | IPv4, HTTP, HTTPS, SIP, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, NTP, RTP |
|---|---|
| Interface protocol | ISAPI, ISUP, SIP, RTP (API) |
| Audio bit rate | G.711ulaw (64 Kbps) G.711alaw (64 Kbps) MP3 (128 Kbps) AAC (128 Kbps) |
| Protection against | Short circuits, Overcurrent, Overheating, Static electricity, Overvoltage, Electrical discharges |
| Rated power | 1,000 W |
| Frequency response | 100 V COM / 70 V COM: 50 ~ 20,000 Hz (±3 dB) RCA Out / 3.5 mm out: 50 ~ 20,000 Hz (±1 dB) |
| Total Harmonic Distortion (THD) | <0.5% at 1 kHz, 1/3 of rated power |
| Signal-to-noise ratio (SNR) | > 90 dB |
| Alarm (Euroblock) | 1x EVAC alarm 1x Alarm input 1x Alarm output If the device connected to the alarm output is "normally closed", connect: 1A to GND; if it is "normally open", connect: 1B to GND. |
| Ethernet (RJ45) | 1x LAN (10 / 100 / 1000 M) |
| Local storage | 4 GB (EMMC) Available space for audio files is 1 GB. |
| Audio | INPUTS: 4x MIC (6.35 mm Jack) -28 dBV, 4.7 kΩ, unbalanced output (cannot be connected without a microphone) 4x RCA (Pin Jack) 0 dBV, 4.7 kΩ, unbalanced output 1x USB 2.0 Bluetooth 5.0 (reception range 10 m) OUTPUTS: 4x Constant voltage output 100 V COM and 70 V COM A single channel supports an output power of up to 250 W 2x RCA (Pin Jack) 0 dBV, unbalanced output 2x Output (3.5 mm Jack) 0 dBV, unbalanced output If the constant voltage mode is set to 100 V, the output interface must be connected to a speaker with a rated voltage of 100 V. Connecting to a speaker with a rated voltage of 70 V could damage the device. |
| LED indicator | 1x Power: Steady white light, device is working properly. 1x USB: Steady white light, device is in USB mode. 1x Bluetooth: Steady blue light, device is in Bluetooth mode. 1x EVAC: Steady red light, EVAC alarm has been triggered. 1x MIC 1: Steady white, MIC 1 input is connected correctly. 1x Module: Steady FLT, indicates an overload or other system fault. 1x CLIP: Steady light, indicates clipping or other anomalies. 1x SIG: Steady light, indicates normal operation. |
| Volume | 1x Total (potentiometer) 4x MIC input (potentiometer) 4x RCA input (potentiometer) 4x Output channel (potentiometer) 1x Treble (potentiometer) 1x Bass (potentiometer) |
| USB | 1x USB 2.0 Supported formats: FAT32 (maximum partition capacity: 32 GB) and EXFAT (maximum partition capacity: 256 GB) |
| Power supply | 100 ~ 240 V AC |
| Consumption | 80 W (standby mode) 200 W (max.) |
| Material | Front panel: PC + ABS Top and bottom panel: SGCC |
| Dimensions | 495.97 (W) × 90.89 (H) × 473.18 (D) mm |
| Weight | 6.6 kg |
| Color | Black |
| Working conditions | Temperature: -10 ~ 50 °C Humidity: <90% (no condensation) |
