DMTECH control repeater
Regular price
€230,58
Final price
Regular price
-8%
€250,00
Sale price
€230,58
Final price
Couldn't load pickup availability
Ready to use
Each product is delivered with the essential accessories and installation instructions. Open the package and you are ready to go.
Free shipping on orders over €200
100% Secure Payments
Industry-leading quality
Do you have any questions?
Ask an expert!
DMTECH control repeater - 2 siren outputs - 2 alarm and fault outputs and 2 configurable relay outputs - Allows up to 8 connected control panels - Required module DMT-M9000-485 - LCD screen and advanced programming menu
📋 SPECIFICATIONS:
• Primary power supply: Switching power supply 187-252V AC 50-60 Hz 65W max.
• Secondary power supply: 2 x 12VDC batteries (up to 7.2 Ah). Ensures a minimum of 72 hours of duration.
• Languages available: Spanish, English, French, Turkish, Romanian, and Russian.
• Siren outputs: 2 x 24VDC siren outputs. Independent and monitored collector outputs
• Relay outputs: 4 Relay outputs: 1 alarm output, 1 fault output, and 2 configurable relay outputs. All support 30VDC 3A max.
• End-of-line resistor: Zones fully monitored by end-of-line resistor (4.7K)
• Auxiliary output voltage: 24VDC. Protected by a 1.85A resettable electronic fuse
• Protection rating: IP30
• Temperature: -5ºC~+45ºC
• Material and Color: ABS, Color: White
• Dimensions: 310 x 240 x 80 mm
• Weight: 1.3Kg
• Recommended cable: Fire-resistant cable with a minimum cross-section of 1.0mm (18AWG).
📦 INCLUDED:
• Control repeater• Battery cables• Fuse
| Primary power supply | Switching power supply 187-252V AC 50-60 Hz 65W max. |
|---|---|
| Secondary power supply | 2 x 12VDC batteries (up to 7.2 Ah). Ensures a minimum of 72 hours duration. |
| Available languages | Spanish, English, French, Turkish, Romanian and Russian. |
| Siren outputs | 2 x 24VDC siren outputs. Independent and monitored collector outputs |
| Relay outputs | 4 Relay outputs: 1 Alarm output, 1 Fault output and 2 configurable relay outputs. All support 30VDC 3A max. |
| End-of-line resistor | Zones fully monitored by end-of-line resistor (4.7K) |
| Auxiliary output voltage | 24VDC. Protected by 1.85A resettable electronic fuse |
| Protection rating | IP30 |
| Temperature | -5ºC~+45ºC |
| Material and Color | ABS, Color: White |
| Dimensions | 310 x 240 x 80 mm |
| Weight | 1.3kg |
| Recommended cable | Fire cable with a minimum cross-section of 1.0mm (18AWG). |
- User manual Link
